Hardware

Size

Access Device:  115*115 *26 mm    Shipping Size: 138*138*98mm

Weight

Qotom-C30 Access Terminal: 180g
Shipping Weight (includes power adapter, packaging, documentation, etc. ): 400g

Power Supply

Input: 100-250 VAC, 50-60 Hz;    Output: 5 VDC, 2 A
Nominal consumption: 5 Watts

Front LED Indicators

Power: connection to power supply  LAN: connection to network
Ready: connection to host PC

Rear Ports

01 – Microphone in
02 – Speaker Out DC Power Input
03 – 3 USB 2.0 Ports,
04 – LAN port (RJ45)
05 – Video port
06 –DC Power Input
07 - On/Off Power Switch  (top)

Connection to Host PC

Onboard LAN 10/100 Mb/s connection or WIFI

Video Resolution

Max 1280*1024, 16bit/64K colors; Widescreen 1440*900 support, or 24Bit

Audio

Stereo output via microphone and speaker port

CPU

Onboard 800 MHz

Memory

Onboard 128MB RAM

Storage

Onboard 128MB Flash

Firmware feature

Windows CE 6.0 integrated RDP protocols, Support system upgrading.

USB

3 USB Port, USB Wi-Fi, USB touch screen,
Through USB converters connected PS / 2 mouse and keyboard

TERMINAL SERVICES SOFTWARE

Max # Users
Per PC

100 users* when using a server host OS (i.e. Windows Server 2003/2008)
30 users when using a desktop OS (i.e. Windows XP/7)

User Software

Qotom terminal services software

Supported Operating
Systems

Windows XP, Windows Server 2000/2003, Windows Vista, Windows 7, Windows Server2008,, Linux and all other OS which has terminal working permission.

SYSTEM REQUIREMENTS AND OPTIONS

Kit Contents

Qotom-C30 Kit includes access terminal, power supply, software installation & user’s guide and other peripherals are NOT included and must be purchased separately.
