| Model: | DIPS9-3040 |
|---|---|
| Brand: | DARDI |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Cutting & Fold-bend Machine |
| Label: | waterjet , water cutter , high pressure system |
| Price: |
-
|
| Min. Order: | 1 pc |
| Last Online:18 Nov, 2024 |
Waterjet cutting system---UHP System Dardi (Model: DIPS9-3040)
Intensifier Qty.: 1
Max. Pressure: 300MPa/40000psi
| UHP System | ||||||
| Model | DIPS6-2230 | DIPS9-3040 | DIPS9-6040 | DIPS9-7540 | DIPS7-3740 | |
| Drive system | ||||||
| Drive system | Motor | |||||
| Pressure system | ||||||
| Pressure system | Intensifier | |||||
| Intensifier Qty. | 1 | 1 | 2 | 3 | 1 | |
| Specification Date | ||||||
| Max.pressure | 300MPa/40000psi | 380MPa/55000psi | 400MPa/60000psi | |||
| Max.Flow rate | 3.1L/min | 3.7L/min | 7.4L/min | 11L/min | 3.7L/min | |
| Power | 22kw/30HP | 30kw/40HP | 60kw/80HP | 75kw/100HP | 37kw/50HP | |
| Pressurization rate | 24:1 | 20:1 | 20:1 | 20:1 | 20:1 | |
| Oil Pressure | 0-150 bar | 0-200 bar | ||||
| Oil type | 46#(15-40ºC)
Hydraulic oil 46#(Environment 15-40ºC) |
|||||
| Power Supply | 220/380/415VAC 3 Phase | |||||
| Payment Terms: | t/t West Union |
|---|---|
