| Model: | W-1010AU |
|---|---|
| Brand: | PRUSP |
| Origin: | Made In China |
| Category: | Industrial Supplies / Plate Making & Printing Machine |
| Label: | screen washer |
| Price: |
-
|
| Min. Order: | 1 pc |
| Last Online:07 Sep, 2021 |
Applied in screen washing process
·Double safety device ensures the safe operate
·Powerful vacuum table provides accurate and consistent position for substrates
·Squeegee, flood bar and the table can be adjustable
·Imported switch, motor, rail and PLC make the performance perfect
·R ed built framework and anti-scrape lacquer improve its finishing
|
Model Data |
W-1010AU |
W-1214AU |
|
Max. Frame Size |
1000×1000mm |
1200×1400mm |
|
Max. Air Pressure |
36Kpa |
|
|
Light Source |
Yellow & White |
|
|
Water Spray Mode |
Parallel & Cross |
|
|
Infall Diameter |
22.5mm |
|
|
Outfall Diameter |
30mm |
|
|
Powder |
380V×3Ph×7KW×50HZ |
|
|
Weight |
470kg |
680kg |
|
Dimension |
1600×1200×2100mm |
2140×1200×2200mm |
Custom model can be made on order
| Payment Terms: | TT, LC or western union |
|---|---|
