| Model: | AL1512 |
|---|---|
| Brand: | LM |
| Origin: | Made In China |
| Category: | Industrial Supplies / Other Industrial Supplies |
| Label: | loading arm , manufacturer , folding stair |
| Price: |
US $45000
/ set
|
| Min. Order: | 1 set |
| Last Online:29 Sep, 2018 |
Our land loading arm is especially designed for transporting fluid between piping system and tanker, which shall be designed for different tanker, liquids and site conditions.
Equipped with loading platform, folding stairs and safety cage to make the land loading arm into a complete loading system.
By level location or quantitative monitoring, while fluid level exceed the present value, provide the sound and visual alarm or the remote signal.
According to the products, models and requirements of customers, the operating modes could be manual, pneumatic or hydraulic etc.
AL1512 is a typical of closed loading arms. It can be easily operated, installed and maintained and has good vapor recovery ratio.
Places Applied: Closed top loading
Applications: Product liquid chlorine, especially for highly volatile and toxic liquids.
Nominal diameter: DN50 (liquid), DN50 (gas)
Working temperature range from -196 to 250ºC
Working pressure PN1.0 to PN4.0
Material of pipeline: carbon steel, stainless steel, aluminum, low-temperature steel, PTFE lined etc.
|
AL1512 is a typical of closed loading arms. It can be easily operated, installed and maintained and has good vapor recovery ratio. |
|
|
Places Applied |
Closed top loading |
|
Applications |
Product liquid chlorine, especially for highly volatile and toxic liquids |
|
Nominal Diameter |
DN50 (liquid), DN50 (gas) |
|
Working Temperature |
-196~250℃ |
|
Working Pressure |
PN1.0~PN4.0 |
|
Material of pipeline |
Carbon steel, stainless steel, aluminum, low-temperature steel, PTFE lined etc. |
