| Model: | - |
|---|---|
| Brand: | MTC |
| Origin: | Made In China |
| Category: | Industrial Supplies / Other Industrial Supplies |
| Label: | step tile machine , glazed tile machine , roll forming machine |
| Price: |
US $20
/ set
|
| Min. Order: | 1 set |
| Last Online:03 Dec, 2015 |
Picture For Reference Only.
As we know, people, especially the Europeans, are more and more preferring the stepped roofing sheet, or called step (roofing) tile, or glazed (roofing) tile. So glazed roofing tile roll forming machine or step tile roll forming machine is favored in Europe. Our glazed roofing tile roll forming machine or step roofing tile roll forming machine is able to produce the step tiles or glazed tiles fully automatically from decoiling, roll forming, hydraulic pressing, hydraulic cutting and running out to supporting tables.
Below is the General Parameters for Reference Only.
Material Thickness: 0.4mm-0.8mm
Forming Stations: 14
Speed of Forming: 3m-5m/min
Roller Diameter: 72mm-80mm
Required Power: 4.0-7.0KW
Hydraulic Power: 5.5KW
The Dimension of Roll Forming Machine: 8500mmX1500mmX1200mm
Weight of Forming Machine: 6-8T
WE CAN ALSO MANUFACTURE ACCORDING TO CUSTOMER'S DRAWING AND REQUIREMENT.
Tags: step roofing tile roll forming machine, glazed roofing tile roll forming machine, roofing tile roll forming machine, metal tile roll forming machine
| Payment Terms: | T/T |
|---|---|
