Features
      1.  New generation LED display multi-function equipment, integrating LED processor, mixed video (including
           CVBS, VGA, DVI, SDI) matrix switching, zoom splicing or point-to-point splicing.
      2.  Multi-format analog and digital signals input, including 16 x CVBS, 16 x VGA, 7 x DVI, 7 x SDI.
      3.  9 groups 18 channels DVI outputs, each group maximum pixels 1920 x 1080p or 1600 x 1200 / 60Hz.
      4.  Multi-screen across display, image roaming, arbitrary scaling across size.
      5.  Seamless switching, fading-in / fading-out between any two input signals.
      6.  Supports text overlay, AIAO(Any In Any Out) function allows for displaying any capturing picture in
           specific area on the screen.
      7.  Zoom synchronization splicing, frame synchronous technology, no miss alignment or delay between
           two adjacent image output, to make sure horizontal and vertical image synchronization, the image will
           not tear.
      8.  Supports Point-to-Point extended splicing, Stand-one unit supports maximum horizontal 15360 pixels
           or vertical 9600 lines.
      9.  Multiple pre-save splicing models call, seamless switching between models.
      10. Insert card design. Input capture cards, output cards, fans, power and other major modules are plug-in
            design. Flexible card design has brought great convenience for everyday use, maintennance. It is
            unnecessary to disassemble the chassis when replacing the failed components. Just remove the failed
            module and replace it which will not affect other modules normal functions.
      11. N+1 redundant power supply design, more reliable operation.
      12. Control way, serial port, USB or PC software interface.
