~• Support HD-TVI, IPC,AHD and analog cameras with adaptive access
• Support Cloud storage( Google Drive or Drop Box)
• Support Smart Face Detections&Premieter analysis
• Long transmission distance over coax cable
• Up to 4/8/16-ch synchronous playback
Model
FST-D6104CT-E*
FST-D6108CT-E*
FST-D6116CT-F8
CPU/AD
HI3520D(V200)+2816
HI3520D(V300)+2816
HI3521A+2816
Operation System
Embedded Linux
Video&Audio input
Video Input
4CH
8CH
16CH
CVBS、TVI、AHD、CVI Signal Adaptive Compaible，Access to the Optional IP Cameras
support TVI/AHD Camera reverse control（UTC）
BNC interface（1.0Vp-p,75ohms）
Network Video
24Mbps
48Mbps
96Mbps
Up to 1080P@30FPS
Audio Input
1CH，RCA interface (2Vpp,1Kohms)
Bidirectional Talk
1-way voice intercom reuse
Video&Audio output
CVBS output
1CH,BNC interface（1.0Vp-p,75ohms）
VGA
1CH,1920×1080,1280×1024,1366×768,1280×720,1024×768 Resolution Optional
HDMI
Standard 1.4a
1920×1080,1280×1024,1366×768,1280×720,1024×768 Resolution Optional
Audio output
1CH,RCA interface (Line out,2Vpp,300ohms)
1CH&4CH（Optional）,RCA Interface (Line out,2Vpp,300ohms)
Intelligent Analysis
N/A
1CH Face detection or 4CH Perimeter detection
Video&Audio Encoding
Real-time Monitor Resolution
1080P(Only Network) ,Half-1080P，720P，WD1，D1
Video Encoding Profile
H.264 High Profile@Level4.2
Encoding resolution
Main stream：Half-1080P，720P，WD1，D1 optional
Auxiliary Stream：CIF，QCIF optional
Encoding Ability
4CH 720P@25FPS or 4CH Half-1080P@22FPS
8CH 720P@12FPS or 8CH Half-1080P@12FPS
16CH 720P@12FPS or 16CH Half-1080P@12FPS
Video Frame Rate
1～25fps
1～12fps
Encoding Control
Qualified rate, variable bit rate is optional
Video Bit Rate
32Kbps~4096Kbps
Stream Type
Composite/Video Streaming
Audio Encoding
G.711A
Audio Bit Rate
64Kbps
Dual stream
Support,Up to CIF@6FPS
Video&Audio Decoding
Video Decoding Porfile
H.264(Up to High Profile@Level4.2）
Synchronous Playback
Up to 4CH
Up to 4CH
Up to 8CH
Decoding Ability
1CH 720P@25FPS or 1CH Half-1080P@22FPS
4CH 720P@12FPS or 4CH Half-1080P@12FPS
8CH 720P@12FPS or 8CH Half-1080P@12FPS
Other Function
Bidirectional Talk
two-way voice intercom function
Motion Detection
Zones: 396(22×18)Multiple detection zones,Variable Sensitivity levels
Regional Block
Each Channel support 4 Regional block pieces
Picture Capture
Support JPEG Capture
HDD Interface
SATA
1 SATA interface
1 SATA interface
2 SATA interfaces
Max Capacity
Unlimited
External Interface
Network Interface
1 RJ45;10M/100M Adaptive Ethernet Interface
1 RJ45;10M/100M Adaptive Ethernet Interface
1 RJ45;10M/100M/1000M Adaptive Ethernet Interface
USB Interface
2USB*2.0 Interfaces
3USB*2.0 Interfaces
RS-485
N/A
N/A
Support
Structure
Dimensions
250*235*45mm
250*235*45mm
335*275*50mm
Installation
Desktop Installation
Electrical Properties
Power
DC +12V 2A
DC +12V 4A
Working Temperature
0℃--＋55℃
Working Humidity
10％--90％
Consumption
6W(Without HDD)
7W(Without HDD)
9W(Without HDD)
