Working Principle

 [ Filtering ] Liquid flows into the filter via the inlet, part of liquid flows directly through filter elements from the lower ends; another part of liquid flows through the distribution pipe and into the upper part of the filter and then flows into the filter elements from the upper and lower ends at the same time,and then flows through the internal surface of filter element and goes out from the outlet. Impurities are intercepted by the elements and the filter cake slowly accumulates, which leads to gradually pressure drop increasing between the inlet and outlet. It indicates that the filter cake reaches certain thickness,and the flux of filter element becomes lower

[ Back-flushing ] When the preset pressure drop or time exceeds, the self-cleaning program is triggered. The gear motor drives the cleaning arm to aim at one element to partly cap the upper end of the element and connect its lower end to the cleaning nozzle. And then the cleaning valve opens and connect the element and discharging pipe. the differential pressure between the element’s outside and discharging nozzle will make the filtrate back-flush the filter element, filter cake dislodged and be purged downward into the sewage pipe. After one element cleaned, the cleaning valve closes and the cleaning arm aims at the next one. When all filter elements cleaned, the entire back-flushing sequences are completed.

Applicable Industries

Water treatment, steel, pulp and paper, mining,petro-chemical, precision machining, municipal, irrigation etc.. channel, the gear motor will stop and the next element is cleaned.

Typical  Applicable Liquids

Groundwater, seawater, freshwater, reservoir water, pond water, cooling circulating water, freezing water, high and low spraying water, squirt water, heat exchanging water, sealing water, bearing cooling water, oil wells injection water, recycled process water, machining coolant, cleaning agents, cleaning water, etc..

Filtration Function

Remove large particles, purify liquids, protect key equipment  Filtration type: Back-flushing filter, automatic continuous online filtration
