Combine Woodworking Machine,ML392E.B,ML392CII,ML392FII

Combine Woodworking Machine,ML392E.B,ML392CII,ML392FII 1

Combine Woodworking Machine,ML392E.B,ML392CII,ML392FII 2

Model:	-
Brand:	SHOOT
Origin:	Made In China
Category:	Industrial Supplies / Tools / Woodworking
Label:	woodworking machine , machine , machinery
Price:	-
Min. Order:	5 pic

Inquire Now

Member Information

Yantai Shoot Woodworking Machine Co.,Ltd

Biz MemberShan Dong - China

Last Online:16 Jan, 2025

Product Description

COMBINE WOODWORKING MACHINE
MODEL: ML392E.B

1.1 Surface planer
Arbor dia.	80mm
Arbor speed	5000r/min
Blade size	260x30x3mm
Max. planing width	250mm
Max. removal	3mm
Dust outlet dia.	100mm
Guide angle	0--45degree

1.2 Thickness planer
Max. planing width	250mm
Range of thickness	6-240mm
Max. removal	3mm
Feeding speed	7m/min
Dust outlet dia.	100mm

1.3 Drilling
Max. drilling dia.	3-16mm
Max. drilling depth	80mm
Motor power	1.5kw/220v(380v)/50hz
N.W./G.W.	180/230kg
Packing size	126x57x105cm

COMBINE WOODWORKING MACHINE
MODEL: ML392CII

1.1 Surface planer
Arbor dia.	72mm
Arbor speed	3500r/min
Blade size	210x30x3mm
Max. planing width	200mm
Max. removal	3mm
Length of surface tables	850mm
Guide angle	0--45degree

1.2 Thickness planer
Max. planing width	200mm
Range of thickness	6-90mm
Max. removal	3mm
Feeding speed	6.5m/min

1.3 Drilling
Max. drilling dia.	12mm
Max. drilling depth	90mm
Motor power	1.5kw /220v(380v)
N.W./G.W.	120kg/150kgs
Packing size	108x68x70cm

COMBINE WOODWORKING MACHINE
MODEL: ML392FII

1.1 Surface planer
Arbor dia.	72mm
Arbor speed	4000r/min
Blade size	260x30x3mm
Max. planing width	250mm
Max. removal	3mm
Length of surface tables	960mm
Guide angle	0--45degree

1.2 Thickness planer
Max. planing width	250mm
Range of thickness	6-120mm
Max. removal	3mm
Feeding speed	6.5m/min

1.3 Drilling
Max. drilling dia.	12mm
Max. drilling depth	90mm
Motor power	1.5kw /2.2kw/220v(380v)
N.W./G.W.	170kg/210kgs
Packing size	113x68x70cm

Product Image

Img 1

Img 2

Img 3

Img 4
