Scope of application

       Transformer Oil Oxidation Stability Tester designed and made as per the Industry Standard of People’s Republic of China SH/T0206-92 “ Test Methods for Oxidation Stability of Transformer Oil” transformer oil oxidation stability tester determine the oxidation stability of transformer oil to determine the oxidation stability of transformer oil.

   This instrument has a reasonable structure, stable performance, simple operation, andis ideal for analysis anddetection equipment.

Function characteristics

1,heated metal bath system:

Aluminum metal as The bath body to avoid The oil, andoil andgas pollution, but also to avoid accidents.

2,Temperature control system:

Intelligent temperature control device with a microprocessor with self-tuning, self-diagnostic function, PID parameters regulate temperature andauxiliary heating automatically shutdown, thus High precision temperature control, reliable performance.

3, with six test bath, either for a sample test can also be carried out up to six sample test, convenient andflexible.

4, equipped with a 6 meter, can be adjusted separately anddirections 6 pass into a gas flow rate of The oxidation tube.

5, equipped with a digital timer, The time for setting andrecording test.

Technical parameters

1 Power supply: AC220V 50Hz, power consumption:  1100W.

2,Temperature control: automatic temperature control digital temperature control table.

3,Measuring range: room temperature ~~ 160 ° C,

4 Temperature Accuracy: set temperature ± 0.2 °C.

5,Temperature components: thermal resistance.

6, The number of samples: 6-way, at The same time for six samples.

7 Heating method: metal bath
