RAINBOW MACHINERY 2000L beer brewing equipment

Model:RM2000L
Brand:RAINBOW
Origin:Made In China
Category:Industrial Supplies / Food, Beverage & Cereal Machine
Label:beer machine , brewery , beer brewing
Price: US $69800 / pc
Min. Order:1 pc
Inquire Now

Member Information

Detail

Jinan Rainbow Machinery Co., Ltd.

Biz MemberShan Dong - China
Last Online:08 Nov, 2022

Product Description

Company Profile:

We, Jinan Rainbow Machinery Co., Ltd  are a professional manufacturer and leading supplier of good quality beer brewing system, ranging from 100L-20000L per patch (used for home, pub/hotel, factory, etc.) at a very competitive price, with product design, production, sales, and installation support.

We have been exporting beer brewing tanks to many places like USA, Canada, Ecuador, Germany, France, Czech Republic, Finland, Norway, Switzerland, Australia, Taiwan....etc.



 MAIN CONFIGURATIONS:

 This brewhouse system includes 3 tanks(mash tun/lautering tun, brew kettle/whirlpool, hot liquid tank), please check the details in the following chart.

Optional:        1- mash/brew kettle, lauter tun/whirlpool

                  2- mash tun, lauter tun, brew kettle/whirlpool

                  3- mash/brew kettle, lauter tun, whirlpool

                  4- mash tun, lauter tun, brew kettle, whirlpool

The 2000L brewing system configuration for your reference.

Items

Equipment

Specification

Quantity

(PCS)

Malt miller

Malt miller

500kg/hour

1

Brew house

Mash tun/lautering tun

2000L

1

Brew kettle/whirlpool

2000L

1

Hot liquor tank

2000L

1

Plate heat exchanger

20 m2

1

Pump

5 m³/h

2

Working platform



1

Fermentation

Fermenter

2000L

6

Yeast tank

50L

1

Wort oxygenator



 1

Cooling unit

Glycol water tank

3000L

1

Cooling compressor

7hp

2

Water pump

3 m³/h

1

CIP unit

Alkali tank

150L

1

Sterilization tank

150L

1

Pump

3 m³/h

1

Control unit

Siemens PLC controlling system

1

Filter system

Kieselguhr filter machine

500L/H

1

Bright beer tank

2000L

1

Spare parts

All necessary spare parts such as pipes, valves, gauges and clamps…etc.

Heating source: electric, baine-marie heating, gas fired or steam

Material: stainless steel 304/304L/316

Warranty: 36 months



Main features of brewhouse and fermentation:

Brewhouse system:

1) - interior wall stainless steel 304, 3mm;

    -exterior wall stainless steel 304, 2mm

2)  -Dome top, top manway with glass

    -Side manway, cone bottom 160 degree

3)  -insulation: polyurethane/rockwool 100mm;

    - with inside CIP washing ball

    - raking agitator

    - removable false bottom

    - sparging arm, sight glass

      -Tangentiainlet for whirlpool

      -Thermowell for temperature sensor and thermometer....



Fermentation system:

1) - Interior wall stainless steel 304, 3mm;

   -exterior wall stainless steel 304, 2mm

 2) -Dome top, conical bottom,

    -Side mounted manway

3) -Insulation: polyurethane 100mm

4) -Glycol cooling jackets on both cylinder and cone

5) - Inside 360 degree rotating CIP washing ball;

   - CIP arm

   - Pressure gauge

   - safety&vacuum valve on top

    - sample valve

   - rotating racking arm

   - thermometer

    -carbonation stone (optional)

   - dry hops port on top

 6) -100% TIG welding with pure argon gas shield

       -Interior Finish: Mirror polishing to 0.4~0.6μm without dead corner

    -Testing pressure: 3 bar

    -working pressure: 1.5-2 bar



Cooling system

CIP washing system

Controlling system



For Your Reference:

 1. We have the capacity of 100L, 200L, 300L, 500L, 1000L, 1200L, 2000L, 3000L, 5000L, 8000L, 10000L...( 1bbl, 2bbl, 5bbl, 10bbl....) per patch for your reference.

      It can be customized, such as the capacity, material, voltage(like 380v, 50Hz, 3phases),    heating source, etc.

 2. The brewer can also brew draft beer, pale beer, brown beer, stout beer etc,

      to meet different taste of customers.

 OPTIONAL:

 Beer bottling line: bottle washing machine, filling machine, capping machine,

 pasteurization tank, labelling machine.

 Kegs washer and filler.

 Beer kegs(10L,20L,30L,50L...).

 Steam boiler.






Payment Terms:TT/LC
