Post Green Color aluminum composite panel
1. 12 year production history
2. 20 year warranty for PVDF
3. 270000sqm/month
4. ISO9001,CE&SGS
Front: smooth alu coil with PE | PVDF paint(PPG, Beckers) coated
Core: excellent nontoxic polyethylene | fireproof
Back: alu.coil with PE coated
Surface coating thickness: 25um~32um
Aluminium Alloy: AA1100 | AA3003
specifications and sizes:
| Panel Thickness | 2mm,3mm,4mm,5mm,6mm is avaliable |
| Aluminum Thickness | 0.5mm,0.4mm,0.3mm,0.21mm,0.18mm,0.15mm,
0.12mm,0.1mm |
| Width | 1220mm(regular),1250mm,1300mm,1500mm,
1550mm,1570mm,1575mm(Maximum) |
| Length | 2440mm(regular),and tailored by customer’s offers,5800mm(Maximum) |
| Standard size | 1220(Width)x2440(Length)x3mm(Thickness);
1250(Width)x2440(Length)x4mm(Thickness); |
Qty/20'FCL: 4mm/4000qm, Qty/20'FCL: 3mm/4500sqm
Available colors:
Ordinary colors : more than 30 kinds of Solid colors and Metallic color reference.
Customized colors , RAL| PANTON colors available;
Mirror effect: Gold mirror, silver mirror effect available.
Brushed effect
Wood | Marble designs: vivid wood | marble patterns can me print on surface with life valid of over 15 years. More than 100 kinds of wood/marble designs are available.
Packaging & Shipping
seaworthy packing:1*20' FCL loading about 1200 sheets . 1. Bulk Packing (Recommend building panels) 2.Wooden Pallet Packing (Recommend Signage Advertising Panels) 102~105 sheets per pallet ; 1*20' FCL loading 4~8 pallet ,1*40' FCL loading 12~16 pallet .USD 50 per Fumigation wooden pallet.
