| Model: | UD-481 Series |
|---|---|
| Brand: | Quick CNC |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Engraving & Etching Machine |
| Label: | CNC router , furniture machine , woodworking machine |
| Price: |
-
|
| Min. Order: | 1 pc |
| Last Online:09 Jul, 2023 |
|
Model |
UD-481 |
|
X-Y-Z axis working area |
1,300 x 2,550 x 300mm |
|
Machine size |
2,080x 3,250mm |
|
Repositioning resolution |
0.02mm |
|
System Resolution |
0.0025mm |
|
X-Y movement |
rack and pinion, gear drive/Taiwan |
|
Z movement |
ball screw drive/Germany |
|
Guide |
Linear ￠25 square/Taiwan |
|
Max. speed |
60,000mm/min |
|
Max. cutting speed |
30,000mm/min |
|
Spindle power |
9kw Italy HSD (ISO30, fan cooling ATC) |
|
Spindle speed |
24,000rpm |
|
Tool magazine |
8 pcs tools, linear type |
|
Inverter power |
11kw |
|
Drive motors |
Yaskawa Servo/Japan |
|
Working voltage |
AC380V/50-60Hz, 3-phase |
|
Command code |
G code |
|
Computer interface |
USB 2.0 |
|
Collet |
ER32- 3.175mm, 6mm, 8mm, 12.7mm |
|
Software |
Artcam & Alphacam Software/UK |
|
Controls |
SYNTEC system/Taiwan |
|
Packing dimensions |
3720 x 2180 x 2150mm,1600kgs |
|
Standard equipment included |
1. Manual oil lubrication system 2. Dust hood 3. T-slot vacuum table 4. Regenerative blower 7.5Kw /Taiwan 5. Tool shanks |
