The Cutting machine can greatly improve the work efficiency, reduce labor cost, improve product quality.

Apply for cutting scarf, fabric etc. first longitudinal cutting then crosscutting.

Two parts:

1. Full Automatic longitudinal cutting part: automatic positioning, through the photoelectric control system automatically track the scarf required cutting position, then cut the scarf by Ultrasonic Cutting Heads, safe, high efficiency, energy saving and durable.

2. Full Automatic cross direction cutting part: through the photoelectric control system automatically accurate positioning the scarf required cutting location, then distracting fringes by teeth plate, cutting accurately the required cutting part. Make the scarf fringe size stable after cutting.

The crosscut blade, single blade or dual blade and distance, can be made by customer requirement.

Technical Data:

1.Working width:2000mm

2.Working Speed: 0~ 20 m/min (Speed adjustable)

3.Capacity: 2.5KW

4.PLC Control system

5.Ultrasonic Cutting Heads

6.Weight: 3000kg

7.Machine Dimension:L*W*H 500cm*350cm*210cm

8. Warranty: 12 months

Scarf Cutting machine testing
