| Model: | Shine 9L |
|---|---|
| Brand: | ADE Tech |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Components / Diode & Triode |
| Label: | transparent led scre , transparent led scre , transparent led scre |
| Price: |
-
|
| Min. Order: | 5 pc |
| Last Online:07 Mar, 2018 |
LED display screen transparent led display screen
>>Shine Series Transparent LED Display
|
Shine Series Transparent LED Display |
|
High transparency. Real high transparent LED display,up to 80% transparency. PCB thickness only2.3mm, vertical transparency reach 170°.Enable vertical see-through effect, extraordinary experience.
|
|
|
|
Extremly light weight. Only 3.5kg/tile(9.7kg/㎡),the toppest light-weight transparent LED display in the market. Your workers will love this transparent LED display surely!
|
|
Slim and clean design. Thickness only 6.3cm(including Electronly Box), 1.3cm(not including Electronic Box). Clean design without extra cables or accessories.
|
|
|
Stable Installation. Thanks for the aluminium & stainless steel structure design,the transparent LED display is not only thin and light weight,but also high reliable on stacking or suspended installation.
|
|
Extremly fast installation. Thanks for fast-locks and quick-plugs,as well as light-weight screen-body,it’s easy for installing. 10 minutes for assembling or disaseembling.Much faster than similar LED display product.Save much of your time.
|
|
|
Easy Maintainence, Just Plug in and out front side.
|
|
Stacked or Suspended installation are available. |
MORE INFOMATION PLEASE VISIT:WWW.ADEDISPLAY.COM
LED display screen transparent led display screen
>>Specification
|
Shine 4 Shine 4L |
Shine 6 Shine 6L |
Shine 9 |
Shine 9S Shine 9SL |
||||
|
Pitch |
X:P4.6875 mm |
X:P6.25 mm |
X:P9.375 mm |
X:P9.375 mm |
|||
|
Y:P6.25 mm |
Y:P9.375 mm |
Y:P12.5 mm |
Y:P9.375 mm |
||||
|
LED |
1921SMD |
2020SMD |
1921SMD |
2020SMD |
1921SMD |
1921SMD |
2020SMD |
|
Nationstar |
Nationstar |
Nationstar |
Nationstar |
Nationstar |
Nationstar |
Nationstar |
|
|
Brightness |
5000 Nit |
3000 Nit |
5000 Nit |
3000 Nit |
4000 Nit |
4000 Nit |
2000 Nit |
|
Density |
34133 PX/m2 |
17067 PX/m2 |
8533 PX/m2 |
11378 PX/m2 |
|||
|
Scan Mode |
1/4 Scan |
1/4 Scan |
1/4 Scan |
1/4 Scan |
|||
|
Size |
60×60 cm,23.6″ x 23.6″ |
60×60 cm,23.6″ x 23.6″ |
60×60 cm,23.6″ x 23.6″ |
60×60 cm,23.6″ x 23.6″ |
|||
|
Module Resolution |
128 x 96 |
96 x 64 |
64 x 48 |
64 x 64 |
|||
|
Weight |
3.5kg/tile(9.7kg/㎡) |
3.5kg/tile(9.7kg/㎡) |
3.5kg/tile(9.7kg/㎡) |
3.5kg/tile(9.7kg/㎡) |
|||
|
Transparency |
75% |
80% |
82% |
80% |
|||
|
Viewing Angle |
120。 |
120。 |
120。 |
120。 |
|||
|
IP Degree |
IP 20 |
IP 20 |
IP 20 |
IP 20 |
|||
|
Working Voltage |
DC 5V |
DC 5V |
DC 5V |
DC 5V |
|||
|
Input Voltage |
AC 96-260V |
AC 96-260V |
AC 96-260V |
AC 96-260V |
|||
|
Power Consumption |
Max. 800W /㎡ |
Max. 800W /㎡ |
Max. 800W /㎡ |
Max. 800W /㎡ |
|||
|
Thickness |
6.3cm (With Electronic Box) |
6.3cm (With Electronic Box) |
6.3cm (With Electronic Box) |
6.3cm (With Electronic Box) |
|||
|
1.3cm(Without Electronic Box) |
1.3cm(Without Electronic Box) |
1.3cm(Without Electronic Box) |
1.3cm(Without Electronic Box) |
||||
>>About ADE TECH
ADE Tech is a manufacturer focusing on creative and smart LED display,which is including flexible LED display,transparent LED display,and provides quick customized solution like Triangle,Round,Cylinder LED display.
ADE believes Attitude is Everything! ADE is committed to provide not only high quality product,but also the best solution for your projects or events.
ADE’s R&D team, with their 7 years’ rich experience,using latest technology developing every LED display carefully and attentively. As the pursuit of perfection but for their extremely harsh,the products are not just “Passed”.
ADE is always the best helper for your project,because the quick customized service.Speed defines the winner.
Quick customized service-Best helper for your special project.
Good Quality-We only provide good quality product,with at least 5 years life span.
Technique manual-If the LED display is strange to you,don’t worry,we provide manual to let you know how simple it is.
Maintenance-Full experienced engineers will ensure your LED display performing well for many years.
5S- Our factory implements 5S standardization management,ensure the products manufactured by highest standards.
CE ROSH UL,All of the LED display products are with CE ROSH certificate,some of the power supply can be achieved UL certificate.
Attitude means everything,our attitude will surely let you believe again!
Thanks for your reading.
