spiral wound gasket with inner and outer ring

spiral wound gasket with inner and outer ring 1

spiral wound gasket with inner and outer ring 2

spiral wound gasket with inner and outer ring 3

Model:	ZR-SW700 IOR
Brand:	SINSTON
Origin:	Made In China
Category:	Industrial Supplies / Machine Hardware / Sealing & Gaskets
Label:	spiral wound gasket , graphite gasket , PTFE gasket
Price:	¥18 / pc
Min. Order:	100 pc

Inquire Now

Member Information

Cixi Sinston Sealing Material Factory

Biz MemberZhe Jiang - China

Last Online:03 Nov, 2024

Product Description

Spiral-Wound gasket is formed of V-shaped metallic stripe and soft non-metallic filler by means of piled, spiral wound and connected its end and beginning by dot welded. Depend on its excellent compression resilience it is suitable for sealing spots where the alteration of temperature and pressure are frequent. It can be used as the static sealing element of pipe, valve, pump, thermal exchange, condensing tower, plain hole and man hole of flange, etc. It has been widely applied in the fields of petrochemical, mechanical manufactory, power station, metallurgy, shipbuilding, medical and pharmaceutical nuclear power station and navigation, etc.
APPLICATION:
We can produce according to ASME, BS, JIS and EN(DIN) standards or client request.
　

Products	Style	Flange	For example
Basic type SWG	ZR- SW 700	Tongue and Groove	304/PTFE
SWG with inner ring	ZR- SW 700 IR	Male and Female	304 304/FG
SWG with outer ring	ZR- SW 700 OR	Raised face Flat face	304/ASB CS
SWG with inner & outer rings	ZR- SW 700 IOR	Raised face Flat face	304 304/FG CS
SWG for heat exchanger	ZR- SW 700H	Heat exchanger	304/FG with 1 bar of DJ
Special shape SWG	ZR-SW700S	Special	Oval

Style	Structure	Hoop material	Filler material	Inner & outer ring material	Normal thickness mm
					Gasket	Inner & outer ring
ZR-SW700	Without rings	304(L);316(L) 321;317L 31803 Monel, Ti,Ni INC Hast.C/B Zr702 etc.	Graphite, PTFE, Asbestos Non-asb Mica, etc	CS, 304(L), 316(L), 321;317L 31803 Ti,Ni INC Hast. Monel, Zr702	3.2 4.5 (0.175”) 6.4	2 3 (1/8”) 4
ZR-SW700IR	With inner ring
ZR-SW700OR	With outer ring
ZR-SW700IOR	With inner & outer rings

SINSTON ZR-SW700 Basic Type Spiral wound Gasket without Ring

SINSTON ZR-SW700 IR Spiral wound Gasket with Inner Ring

SINSTON ZR-SW700 OR Spiral wound Gasket with Outer Ring

SINSTON ZR-SW700 IOR Spiral wound Gasket with Inner Ring and Outer Ring

Payment Terms:	TT
