| Model: | HHBB-01 |
|---|---|
| Brand: | YT |
| Origin: | Made In China |
| Category: | Industrial Supplies / Construction Machine |
| Label: | Electric chain hoist , electric hoist , chain hoist |
| Price: |
US $391
/ pc
|
| Min. Order: | 1 pc |
| Last Online:29 May, 2019 |
Application:
Electric Chain hoist is typical of unique optimal structure in shortening the distance between the machine body and the beam tracks, applicable to operations in side low buildings, especially suitable for use in temporarily erected plant buildings or on the sites where expansion of effective hoisting spaces inside the buildings is required the Most important parts of the Machine is Chain and brake system.
| Technical Specification | |||||
| Model | HHBB0.5 | HHBB01 | HHBB02 | HHBB03 | |
| Capacity(t) | 0.5 | 1 | 2 | 3 | |
| Standard Lifting Height(m) | 3 | 3 | 3 | 3 | |
| Lifting Speed(m/min) | 6.8 | 6.6 | 6.6 | 5.4 | |
| Lifting Motor | Power(kw) | 0.75 | 1.5 | 3 | 3 |
| Rotation Speed(r/min) | 1440 | 1440 | 1440 | 1440 | |
| Phases | 3 | 3 | 3 | 3 | |
| Voltage(v) | 200-660 | 200-660 | 200-660 | 200-660 | |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 | |
| Operating Motor | Power(kw) | 0.4 | 0.4 | 0.4 | 0.75 |
| (Electric Trolley Type) | Rotation Speed(r/min) | 1440 | 1440 | 1440 | 1440 |
| Operating Speed(m/min) | 11/21 | 11/21 | 11/21 | 11/21 | |
| Phases | 3 | 3 | 3 | 3 | |
| Volatge(v) | 200-660 | 200-660 | 200-660 | 200-660 | |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 | |
| Load Chain Falls | 1 | 1 | 1 | 1 | |
| Chain Specification | Ø6.3 | Ø7.1 | Ø10.0 | Ø11.2 | |
| Test Load(t) | 0.625 | 1.25 | 2.5 | 3.75 | |
| Weight(kg) | 47 | 61 | 115 | 122 | |
| I-Beam(mm) | 58-153 | 58-153 | 82-178 | 100-178 | |
| (Electric Trolley Type) | |||||
| Chain Add Weight Per Meter(Kgs) | 0.81 | 1.1 | 2.3 | 2.8 | |
| Payment Terms: | 50% TT deposit and the balance before delivery |
|---|---|
