| Model: | PC-702 |
|---|---|
| Brand: | LILLIPUT |
| Origin: | Made In China |
| Category: | Computers & AV Digital / Computers / Embedded Computer & SCM |
| Label: | 7'' IPC , 7'' Industrial PC , 7'' Embedded PC |
| Price: |
-
|
| Min. Order: | - |
| Last Online:25 Dec, 2024 |
Features:
CPU: NXP i.MX6DualLite
RAM: 1G DDR3, flash ROM: 8G eMMC
OS: Android 5.1.1, Linux Debian 8.0, WinCE 7.0
Multipoint capacitive touch screen
Aluminum alloy
9-36V wide power voltage
USB host 2.0×2, USB device 2.0×1
RS232×4 / RS232×3+RS485×1 / RS232×2+RS422×1+RS485×1
Gpio input×4, Gpio output×6, CAN Bus×2
Wi-Fi, bluetooth, 3G/4G, PoE for optional
Specifciation:
|
Core |
Processor | Intel Atom Z8350 1.44GHz |
|---|---|---|
| Graphic | Intel HD Graphic 400 | |
| RAM | 2GB LPDDR3 | |
| ROM | 32GB Emmc | |
| OS | Win10, 32-bit(unactivated) | |
|
Display |
LCD Panel | 7" LED Backlit |
| Resolutions | 1280×800 | |
| Brightness | 400cd/m2 | |
| Contrast Ratio | 800: 1 | |
| View Angle | 160°/ 160° (H/V) | |
| Touch Panel | Capative | |
|
Wireless (Optional) |
WiFi | 802.11a/b/g/n 2.4GHz |
| Bluetooth | 4.0 2402MHz~2480MHz | |
| Cellular | 4G/ 3G/ 2G | |
|
Interface |
USB | USB Host 2.0 × 1 / 3.0 × 1 |
| TF card | 1.8v / 2.95v, up to 128G | |
| SIM card | 1.8v / 2.95v, mini SIM | |
| HDMI | HDMI 1.4 Ouput | |
| GPIO | Input×4, output×6 | |
| RS232/485/422 |
RS232×4 RS232×3+RS485×1(Optional) RS232×3+RS422×1(Optional) RS232×2+RS485×1+RS422×1(Optional) |
|
| LAN | 100M×2 | |
|
Mounting |
Bracket Support | 75mm VESA |
|
Power Supply |
DC in | 9-36V |
| Consumption | ≤10W | |
| PoE (Optional) | Power over Ethernet | |
|
Environment |
Operating Temp |
-10℃ - 60℃ |
| Storage Temp | -30℃ - 70℃ | |
|
Mechanical |
Dimensions | 206 × 144 × 30.9 (mm) |
| Weight | 770g |
