Type

Resonance FreCuency

Static capacitance

Resonance Impendence

Size( radial diameter  and length

power

Insulation Impendence

Notes

（KHz）

（pF）

（Ω）

D*H

（W）

(2500VDC)

GPAC-8SS-2540

40±0.8

3100±10%

≤30Ω

25*58

20w

≥100MΩ

PZT8

Small power  (10-40W)

GPAC-8SS-3045

46±1.0

2400±10%

≤25Ω

45*43

35w

≥100MΩ

PZT8

GPAC-4AS-1550

51.0±2.0

1700±10%

≤50Ω

15*58

10W

≥100MΩ

PZT4

GPAC-4AS-1540Y

40±2.0

3400±10%

≤30Ω

15*60

15W

≥100MΩ

PZT4

GPAC-4AS-1540

40±2.0

3400±10%

≤30Ω

15*58

15W

≥100MΩ

PZT4

GPAC-4SS-2540

40±0.8

2400±10%

≤30Ω

25*58

20w

≥100MΩ

PZT4

GPAC-4SH-2540

40±0.8

2400±10%

≤30Ω

30*50

20w

≥100MΩ

PZT4

GPAC-4AH-2560

60±1.5

2300±10%

≤35Ω

30*35

20w

≥100MΩ

PZT4

GPAC-4AS-2565

65±1.5

2300±10%

≤35Ω

25*31

20w

≥100MΩ

PZT4

GPAC-4AS-3055

55±1.0

3100±10%

≤35Ω

30*45

35w

≥100MΩ

PZT4

GPAC-4AH-3050

52±2.0

3100±10%

≤35Ω

38*40

35w

≥100MΩ

PZT4

GPAC-8SH-3517

17±1.0

2550±10%

≤28Ω

78*93

50w

≥100MΩ

PZT8

Middle power  (50-60W)

GPAC-8SH-3820

20±0.8

3800±10%

≤28Ω

59*99

60w

≥100MΩ

PZT8

GPAC-8SH-3823

23±0.8

3800±10%

≤28Ω

59*84

60w

≥100MΩ

PZT8

GPAC-8SH-3825

25±0.8

3800±10%

≤20Ω

59*80

60w

≥100MΩ

PZT8

GPAC-8SH-3828

28±0.5

3800±10%

≤20Ω

59*68

60w

≥100MΩ

PZT8

GPAC-8SH-3833

33±0.5

3800±10%

≤20Ω

48*61

60w

≥100MΩ

PZT8

GPAC-8SH-3840

40±0.5

3800±10%

≤20Ω

48*51

60w

≥100MΩ

PZT8

GPAC-4SS-3528

28 ±0.5

4000±10%

≤20Ω

45*79

50w

≥100MΩ

PZT4

GPAC-4AH-3540

40 ±1.0

4000±10%

≤20Ω

45*55

50w

≥100MΩ

PZT4

GPAC-4SH-3825

25±0.8

5100±10%

≤20Ω

59*80

60w

≥100MΩ

PZT4

GPAC-4SH-3828

28±0.5

5100±10%

≤20Ω

59*68

60w

≥100MΩ

PZT4

GPAC-4SS-3833

33±0.5

5100±10%

≤20Ω

45*61

60w

≥100MΩ

PZT4

GPAC-4SS-3835

35±0.5

5100±10%

≤20Ω

45*55

60w

≥100MΩ

PZT4

GPAC-4SH-3840

40±0.5

5100±10%

≤20Ω

48*51

60w

≥100MΩ

PZT4

GPAC-4SS-3868

67±2.0

5100±10%

≤20Ω

50*65

50w

≥100MΩ

PZT4

GPAC-4SS-3880

79±1.5

4200±10%

≤25Ω

40*54

60w

≥100MΩ

PZT4

GPAC-4SS-38100

100±1.5

5100±10%

≤25Ω

40*57

60w

≥100MΩ

PZT4

GPAC-4AS-38120

120±1.5

5100±10%

≤25Ω

40*58

60w

≥100MΩ

PZT4

GPAC-4SS-38130

129±1.5

4200±10%

≤25Ω

40*54

60w

≥100MΩ

PZT4

GPAC-4SS-38160

160±1.5

5100±10%

≤25Ω

40*57

60w

≥100MΩ

PZT4

GPAC-8SE-3828/40

28/40±1.0

3800±10%

≤30Ω

65*70

60w

≥100MΩ

PZT4

GPAC-4SS-3840/68

38/66±2.0

5100±10%

≤20Ω

50*65

50w

≥100MΩ

PZT4

GPAC-4SS-3840/80/130

38/79/128±2

4200±10%

≤25Ω

40*54

60w

≥100MΩ

PZT4

GPAC-4SS-3840/100/160

38/100/160±2.0

5100±10%

≤25Ω

40*57

60w

≥100MΩ

PZT4

GPAC-8SH-4520

21.5±0.8

5600±10%

≤20Ω

67*92

80w

≥100MΩ

PZT8

Mid-high Power (80-100W)

GPAC-8SH-4528

28±0.5

5600±10%

≤20Ω

67*68

80w

≥100MΩ

PZT8

GPAC-8SH-5028

28±0.5

7200±10%

≤20Ω

67*68

100w

≥100MΩ

PZT8

GPAC-4SH-4520

22±0.5

7600±10%

≤20Ω

67*92

80w

≥100MΩ

PZT4

GPAC-4SH-4525

25±0.5

7600±10%

≤20Ω

67*76

80w

≥100MΩ

PZT4

GPAC-4SH-4528

28±0.5

7600±10%

≤20Ω

67*68

80w

≥100MΩ

PZT4

GPAC-4SH-5028

28±0.5

9600±10%

≤20Ω

67*68

100w

≥100MΩ

PZT4

GPAC-8SH-5020

20±0.5

4650±10%

≤25Ω

79*94

120w

≥100MΩ

PZT8

High power  (above 100w)

GPAC-8SH-2020(5X4)

20±0.5

5000±10%

≤25Ω

35*89

60w

≥100MΩ

PZT8

GPAC-8SH-3020(5X4)

20±0.5

7000±10%

≤20Ω

45*88

80w

≥100MΩ

PZT8

GPAC-8SH-4020(5X4)

20±0.5

10000±10%

≤15Ω

54*88

120w

≥100MΩ

PZT8

GPAC-8SH-4520(5X4)

20±0.5

14500±10%

≤12Ω

64*88

160w

≥100MΩ

PZT8

GPAC-8SH-5020(5X4)

20±0.5

18000±10%

≤10Ω

74*88

200w

≥100MΩ

PZT8
