| Model: | 24V120Ah |
|---|---|
| Brand: | customized |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Battery, Storage Battery & Charger |
| Label: | Robot battery , 24v lithium battery , Lithium battery 24v |
| Price: |
-
|
| Min. Order: | - |
| Last Online:08 Dec, 2023 |
Product Information
Specification:24V120Ah（8 Series）
Cell:Brand Lithium iron phosphate battery
Discharge:Max continuous discharge current 0.5C(60A)
Charge: Max continuous charge current 1C(120A)
Size: L680mm*W280mm*H320mm（Max）
Application : Robot
Product details
Battery Specification: 8S1P/24V/120Ah
Rated Voltage:25.6V
Nominal Capacity:120Ah
Charge Voltage:28.8V
Charge Current:≤120A
Discharge Current:60A
Instantaneous discharge current:100A
Discharge Cut-off Voltage:20V
Internal Resistance:≤100mΩ
Weight:36Kg±1Kg
Overheat protection temperature:55℃
Battery case: Sheet Metal
Li-ion battery protection function: short-circuit protection, overcharge protection, Overdischarge protection,Overcurrent protection, temperature protection, Balanced protection and so on
Product Advantages
1. Brand guarantee：Use power type high rate brand cell
2. Rapid Charge: Sustainable charging current can be reached 1C
3.Life Cycle:over 2000 Times
4. Structure safety：Structural design with vibration, shock resistance and heat dissipation
5. System safety: Equipped with intelligent BMS to monitor battery status and protect battery in real time
