Precitec ProCutter 1.0/2.0 Laser cutting head

Model:Procutter0-6000
Brand:Precitec
Origin:Made In China
Category:Industrial Supplies / Machinery / Cutting & Fold-bend Machine
Label:Precitec Cutting Hea , Collimator Focus len , cutting machine
Price: ¥98000 / pc
Min. Order:1 pc
Inquire Now

Member Information

Detail

Eternal Laser Technology (Suzhou) Co., Ltd.

Free MemberJiang Su - China
Last Online:27 Mar, 2023

View all products. (16)

Product Description

  • motorized focus position adjustment for automatic machine setup and piercing work
  • lightweight and slim design created for fast acceleration and cutting speed
  • drift-free, fast-reacting distance measurement
  • permanent protective window monitoring
  • automated piercing with PierceTec
  • water cooling of the sheet metal with CoolTec
  • completely dustproof beam path with protective windows
  • LED operating status display
  • output of all sensor data via WLAN to APP and machine control possible
  • pressure monitoring in the nozzle area (gas cutting) and in the head
  • ProCutter up to 8 kW (with wave lengths of 1030 - 1090 nm)
    • collimation length: 100 mm
    • focus lengths FF: 125, 150, 175, 200 mm
    • NAmax: 0.13
    • dimension (WxD): 96 x 134 mm
    • weight: 4.2 kg (FF125)

  • ProCutter up to 15 kW (with wave lengths of 1030 - 1090 nm)
    • collimation length FC: 100 mm
    • focus lengths FF: 150, 200 mm
    • NAmax: 0.13
    • dimension (WxD): 96 x 134 mm
    • weight: 4.9 kg (FF150)
