| Model: | TS6601 |
|---|---|
| Brand: | Tensan |
| Origin: | Made In China |
| Category: | Chemicals / Adhesives & Sealants |
| Label: | Waterproof LED RTV , Adhesive Sealant Sil , led silicone sealant |
| Price: |
US $1
/ pc
|
| Min. Order: | 100 pc |
| Last Online:17 Mar, 2021 |
Led Silicone RTV Adhesive for LED Lamp
Features & Benefits
TENSAN LED RTV Silicone Adhesive is semi-flow RTV silicone with good waterproof function and sealing strength. LED RTV Silicone Adhesive can be used for bonding metal, glass, ceramics etc.
1 REACH, ROHS certified
2 MSDS for air/sea shipment
3.Fast curing
4.Non-corrosive to most copper,polycarbonate plastics material
5.Excellent waterproof function
6.Excellent sealing performance
7.Good Performance for insulation
Typical Properties
| LED Silicone | ||||||
| Property | Test Method(ASTM) | Unit | TS6601 | TS6602 | TS6603 | TS6605 |
| Color | Visual | / | Clear | Translucent | White | Black |
| Specific Gravity | Helium Pycnometer | (g/cm³) | 0.92 | 1.05 | 1.4 | 1.2 |
| Viscosity | Brookfield Viscometer | (mpa.s) | 2000 | 50000 | 55000 | 45000 |
| Tack-free Time² | MIL-S-8802E | min | 3-8 | 3-8 | 4-10 | 3-10 |
| Durometer Hardness | D2240 | / | 25 | 35 | 55 | 50 |
| Tensile Strength | D412 | Mpa | 1.6 | 2.0 | 2.5 | 2.3 |
| Elongation at Break | D412 | % | 150 | 200 | 250 | 350 |
| Usage Temperature | Tensan | °C | -55 ~ 180 | -55 ~ 180 | -55 ~ 180 | -55 ~ 180 |
| UL | UL94 | / | HB | HB | V0 | V1 |
Typical Applications
This material is widely applied in LED Industry for housing sealant and outdoor light.
1.Used for LED bulb & Tube & other indoor lights
2.Used for Street light,High bay & other outdoor lights
3.Used for LED auto lights
Packing Information
1. Hard plastic tube 100 ml
100 tubes / carton
2. Hard plastic tube 300 ml
24 tubes / carton
3. Hard plastic tube 2600ml
4 tubes / carton
4. Customized packing is acceptable
Storage and Validity
1.Keep away from children .
2.Stored in a cool, ventilated, dry place.
Shelf life: 6 months
