| Model: | MLWF200 |
|---|---|
| Brand: | Moland |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Filters |
| Label: | fume extractor , dust collector , smoke purifier |
| Price: |
US $462
/ pc
|
| Min. Order: | 1 pc |
| Last Online:07 Apr, 2021 |
Suitable for all kinds of welding (arc welding, secondary welding, MAG welding, gas melting cutting, special welding, etc.), polishing, cutting, grinding and other places to produce smoke and dust.
Performance Description
The smoke and dust purifier has passed the prodcut certification of CCEP China Environmental Productection Industry Association, and the filteration efficiency is more than 99.9%.
To meet the requirements of W3 (high alloy steel) welding fume safety filtering, it meets the requirements of the special rules in the national regulations on the supervision of hazardous substances, and can even realize indoor air circulation if it is used correctly.
Standard Configuation
1- Filteration efficiency (>99.9%) of main filter core (covered polyester fiber)
2- 2m/3m Universal Flexible Inhalation Arm
3- Fault phase protection and overload protection
4- Quick-disassembly filter chuck
5- 5m power cord
6- Spark trap (large particle dust pre-filter)
7- Activated carbon filter (for adsorbing toxic gases)
| MLWF120 | MLWF200 | Spare Parts List | ||
| Motor Power | 1.1KW | 1.5KW | Name | Number |
| Working Voltage | 220V 50Hz | 380V 50Hz | Main Filter Element
dia.325*400mm |
L*3240 |
| Air Volume | 1500m^3/h | 2500m^3/h | ||
| Filtering Accuracy | 0.3um | Suction Arm
dia.160*2000mm |
XQB1620 | |
| Filter Material | Domestic Membrane-coated Filter Element | |||
| Filter Area | 8m^2 | Suction Arm
dia.160*3000mm |
XQB1630 | |
| Cleaning Mode | Manual | |||
| Noise Level | 65dBA | Activated Carbon Filter | HXT120 | |
| Size | 550*550*1050mm | |||
| Weight | 90kg | |||
