| Model: | out series |
|---|---|
| Brand: | vandolite |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electrochemical Products |
| Label: | - |
| Price: |
US $11
/ pc
|
| Min. Order: | 50 pc |
| Last Online:17 Aug, 2021 |
| Technical Specifications | |||||
| Technical drawing | |||||
|
|
|||||
| Schematic light drawing | |||||
 |
|||||
| h(m) | E(lx) | D(m) | |||
| 1 | 79 | 2.50 | |||
| 2 | 19 | 5.00 | |||
| 3 | 8.8 | 7.50 | |||
| 4 | 4 | 10.00 | |||
| 5 | 3 | 12.00 | |||
| Main specifications | |||||
| Lamp category: | LED | ||||
| Power: | 16W | ||||
| CCT: | 2700K/3000K/4000K/5000K | ||||
| CRI: | 80/90 | ||||
| Lumen(lm): | 611 | ||||
| Mountings: | Magnetic Track | ||||
| Environment: | Indoor | ||||
| Optical | |||||
| Lighting type: | Direct | ||||
| LED type: | SMD LED | ||||
| Lighting distribution: | Symmetric | ||||
| Optical type: | Diffuse | ||||
| Electrical | |||||
| Voltage(V): | 24 | ||||
| Dimmable: | Yes | ||||
| Driver: | Remote | ||||
| Driver type: | Electronic | ||||
| Emergency: | Without | ||||
| Insulation class: | Ⅲ | ||||
| Physical | |||||
| Color: | Black RAL9005/white RAL9003 | ||||
| Orientation: | No | ||||
| Weight(kg): |
0.71 |
||||
| Package | |||||
| Number/Ctn(kg): | 10 | ||||
| N.W/Ctn(kg): | 7.1 | ||||
| G.W/Ctn(kg): | 11.2 | ||||
| L*W*H(cm): | 45*38.5*30 | ||||
| Certificates | |||||
 |
|||||
