Industrial Combustible Gas Leakage Detector can be call industrial gas sensor, industrial gas detector, combustible gas detector, flammable gas sensor, ect. It is an industrial safety device for a single or multiple combustible or flammable gas concentration response. Fixed gas detector has catalysis, infrared optical two kinds of type. Catalytic type combustible gas detector is to use refractory metal platinum rose after heating resistance change to determine the combustible gas concentration.

Features:

 * Non-interfering, intelligent detector boundary

 * Output: 4~20mA or RS485

 * Unique automatic fault diagnosis function

 * Catalytic sensor

 * Low energy consumption

 * Detect natural gas, lpg, CH4, alcohol

Specifications:

* Technical Parameter:

* Environmental Parameters:

 Environmental temperature: -40degree ~ 70degree

 Relative humidity: less than 90%R.H

* Technical Parameter:

     Operating Voltage: 16~30V DC

     Operating Current: 120mA

     Output signal: 4~20mA standard signal three-wire system output

* Sensor: Die cast aluminum catalysis incendiary sensors

* Respond: less than 30s

* Measuring range: 0~100%LEL

* Installation Parameter:

     Installation type: Wall-mounted

* Protection Grade: IP65

* Connector: G3/4

Industrial fixed gas sensor widely used in hotels, factories, metallurgy, petroleum, petrochemical, chemical industry, light industry, coking, municipal, gas, pharmacy, sewage treatment and many special industries and fields. It can be detect combustible gases, flammable gases, lpg gas, natural gas, ect.
