Introduction
The principle of the Tester is to measure the octane number of gasoline, the insulation permeability and the electromagnetic induction charge characteristics. By measuring the dielectric properties of the oil and comparing it with the known data model stored in the memory, the result can be determined. The induction device is very, can measure the small dielectric parameter change. So it can detect the octane number petroleum product parameters.

Technical Parameter
1, Measurement items: gasoline for automobiles
2,Operating range: temperature -10℃～+40℃, relative humidity 30%～81%R.H, atmospheric pressure 64～106kPa
3, The Measuring Range Of Octane Number: 40～120 (ON)
4, The Allowable Measurement Error of The Octane Number Meter: ±0.5 (ON)
5,The Floating Range of The Octane Number Meter Measurement Result: ±0.2 (ON)
6, Measuring Time: 20S
7,Output Mode: LCD display, print output
8, Working Power Supply: AC220V 50HZ
9, The Power of The Whole Machine: 50W
10, Instrument Size: 500*480*400mm
11, Net Weight: 15KG

Features
1,Determine the result by measuring the dielectric properties of the oil and comparing it with the known data model stored in the memory;
2, The induction device is very high, which can measure the small changes in dielectric parameters;
3, High precision;
4,Automatic measurement, automatic printing;
