1500℃ Double Spirals Silicon Carbide Heating Rod
Description
| Name: | 1500c Silicon Carbide Heating Rod | Condition: | New |
|---|---|---|---|
| Material: | Silicon Caribide | Type: | Spirals |
| Power Source: | Electric | Voltage: | 12-480v |
| Temp: | 1500c | Shape: | ED, U, W, DB, H, G, GC, SCR, Etc |
| Application: | Electric Industry Heating Process | After-sales Service: | On-line Support Provided |
| High Light: |
1500c Silicon Carbide Heating Rod ,Double Spirals Silicon Carbide Heating Rod ,Double Spirals SiC Heating Rod |
||
1500℃ Double Spirals Silicon Carbide Heating Rod
Silicon Carbide Heating Rod Description
Silicon Carbide Heating Rod is a kind of nonmetal high temperature electric heating element.
It is made of selected super quality green silicon carbide as main material,which is made into blank,silicide under high temperature and re-crystallized. Max temperature 1600 deg C.
Heaters silicon carbide SiC heater have rather large specific resistance. When it is heated in air and the surface temperature of the hot zone reaches 1050°C,it's resistance rate is 600-1400mm2/mm and its resistance value changes as the temperature rises which is negative value from room-temperature to 800 °C and is postive value nature over 800 °C .
Silicon Carbide Heating Rod are capable of high power output, and may be mounted either vertically or horizontally.
We value our customers' feedback, and continue to implement changes and improvements in the quality of SiC heating elements.
With our experience and advanced technologies we are continually developing products to meet the challenge of new applications and industries. With the largest production capacity in the World, and wide range of quality products, we are able to support our customers by supplying the most appropriate heating element for any given application.
Silicon Carbide Heating Rod Advantages
Silicon Carbide Heating Rod Parameters
|
Outer Diameter (OD, mm) |
Hot zone (HZ, mm) |
Cold zone (CZ, mm) |
Overall length (OL, mm) |
Range of resistance (ohms) |
| 8 | 100-300 | 60-200 | 240-700 | 2.1-8.6 |
| 12 | 100-400 | 100-350 | 300-1100 | 0.8-5.8 |
| 14 | 100-500 | 150-350 | 400-1200 | 0.7-5.6 |
| 16 | 200-600 | 200-350 | 600-1300 | 0.7-4.4 |
| 18 | 200-800 | 200-400 | 600-1600 | 0.7-5.8 |
| 20 | 200-800 | 250-600 | 700-2000 | 0.6-6.0 |
| 25 | 200-1200 | 250-700 | 700-2600 | 0.4-5.0 |
| 30 | 300-2000 | 250-800 | 800-3600 | 0.4-4.0 |
| 35 | 400-2000 | 250-800 | 900-3600 | 0.5-3.6 |
| 40 | 500-2700 | 250-800 | 1000-4300 | 0.5-3.4 |
| 45 | 500-3000 | 250-750 | 1000-4500 | 0.3-3.0 |
| 50 | 600-2500 | 300-750 | 1200-4000 | 0.3-2.5 |
| 54 | 600-2500 | 300-750 | 1200-4000 | 0.3-3.0 |
FAQ
1. Is your company accepting customization?
W e have own factory and excellent technical team, and we accept OEM service.
2. Shall you offer samples?
Yes, we can offer the client samples in stock.
3. How to solve the quality problems?
If the products are not conform to customer samples or have quality problems, our company will be responsible to make compensation for it.
4. What is the delivery time?
15-25 days after receiving deposit
If we have the size you need in stock. we will send them 2-3 days, if you order crucible need to produce, the delievey time is about 10-25days.
5. What's your regular practice concerning terms of payment?
A: Payment terms :T/T 30%-50% deposit after order confirm ,the balance after goods ready before shipping or L/C, or Western Union for small amount. Or PAYPAL.
