BRTV09WDS5P0/F0 five-axis servo manipulator

The BRTV09WDS5P0/F0 series is suitable for taking out finished products and nozzles of various types of horizontal injection machines from 120T to 320T. The installation method is different from the traditional horizontal type. The finished product and material head are taken out and placed at the end of the injection machine, which can save machine installation space.The arm form is double section, double arm, up and down stroke 900mm, five-axis AC servo drive, the installation can save the installation space of the injection machine by 30-40%, make full use of the factory building, and increase the production capacity (20-30%), reduce the product The defect rate is high, the safety of operators is guaranteed, labor is reduced, production volume is accurately controlled, and waste is reduced.Five-axis drive and control integrated control system: less signal lines, long-distance communication, good expansion performance, strong anti-interference ability, high repeat positioning accuracy, simultaneous control of multiple axes, simple equipment maintenance, and low failure rate.

 MainSpecification

Power Capacity (KVA) Applicable Molding Machine (ton) Drive Mode Fixture Type 3.5 120T-320T AC Servo Motor Two Suction and Two Holds Traversing Stroke (mm) Pulling Stroke (mm) Up and Down Stroke (mm) Maximum Load (kg) Traversing Arch Total length within 6 meters to be determined 900 5 Take-out time (sec) Full cycle time (sec) Air consumption (NI/cycle) Weight (KG) 1.7 To be determined 9

The above-mentioned cycle time are the results of our company's internal test standard. In the actual application process of the machine, they will vary according to the actual operation.Model representation: W：Telescopic type. D：Product arm + runner arm. S5:Five-axis driven by AC Servo Motor(Traverse-axis、Vertical-axis+Crosswise-axis).

A B C D E 1555 Total length of transverse arch within 6 meters 160 To be determined F G H I J To be determined 174 187 To be determined K L M N O 126 266 To be determined 549 484 P Q To be determined 900
