| Model: | - |
|---|---|
| Brand: | double-decker bus GPS 3G Mobile DVR |
| Origin: | - |
| Category: | Security & Protection / Safety Products |
| Label: | double-decker bus GP |
| Price: |
¥2356
/ pc
|
| Min. Order: | 3 pc |
| Last Online:30 Aug, 2023 |
Mobile Dashcam with Max 4 Channel Video Recording
V5
Product Features:
16 x 720P AHD Video input, support 960P AHD camera.
Waterproof & Dustproof IP67.
2 HDD / SSD slots, and 1 SD card (up to 512GB) for backup (at 4G / Wi-Fi model option).
Internal G-sensor, GPS, 3G and Wi-Fi (5.8 Ghz).
Anti-Shock and Anti-Vibration MIL-STD-810G certified.
Hard drive auto-heating startup in freezing weather.
Operating temperature - 40℃ ~ + 80℃.
24V-36V wide voltage power supply.
Yuweitek V5 16 channel Mobile DVR which can connect and record simultaneously up to 16 cameras and an ethernet port to connect a forward facing IP camera. This DVR is Perfect protect your data well with waterproof & dustproof IP67.
Features:
1. Hidden antenna design, no need to install external antenna.
2. The integrated design of the car camera with external GPS module/antenna or built-in antenna provides better GPS signal and performance than other conventional driving recorder designs, avoiding interference from GPS signal and recorder circuit.
3. Support up to 3 channels of AHD camera input, including 1 channel of 1080P AHD+2 channels of 720P AHD full-frame recording.
4. Support ADAS, DSM, face recognition function (optional).
5. Dual TF card video storage, single card supports up to 512GB.
6. Compatible with H.265/H.264 video encoding.
7. The built-in Wi-Fi is used as a hotspot for wireless connection between the mobile phone and the device. Use the mobile APP to set up functions such as viewing device parameters, status, and playing videos.
8. Support microphone and speaker
9. A built-in yellow and blue two-color indicator light indicates the working status of the equipment, and the hidden design avoids interfering with the driver's sight.
10. Support emergency alarm button.
11. Built-in Mini USB 2.0 for recording data export and equipment maintenance.
13. Support low-voltage protection, when the voltage is lower than 8.5V, the device will automatically shut down (the shutdown voltage value can be set, the default value is 8.5V).
14.9V-36V DC power supply.
15. Working temperature -25℃~+75℃, storage temperature -40℃~+80℃.
|
Parameter classification |
parameter item |
Score indicator |
Remark |
|
Basic parameters |
Exterior |
Dash Camera integrated with terminal |
Max 4-channel video version. |
|
product type |
4G DVR Car Video Terminal |
||
|
network standard |
4G full Netcom |
||
|
Memory |
256MB(Flash)+1GB(DDR) |
||
|
front camera |
1080P, MIPI Camera, 16:9 required, H:112°V:55° |
||
|
in-car camera |
AHD 720P, with light sensor/infrared night vision, |
||
|
DSM camera |
AHD Camera, single pass, infrared night vision, 16:9 required, H=60° V=42° |
||
|
Hardware function
|
GPS |
Support: GPS+BDS |
|
|
Wi-Fi |
802.11b/g/n |
||
|
trumpet |
8 ohms 1.5 watts, 1 channel, with sound cavity |
||
|
MIC |
Built-in dual silicon microphone design |
||
|
Accelerometer |
3-axis accelerometer |
||
|
Interface |
micro 5Pin USB |
USB×1, data interface |
|
|
BMW connector |
8Pin power supply (5-way IO input, SOS*2) |
||
|
5557-4 |
RS232×1 |
||
|
SIM card holder |
Micro SIM |
||
|
TF card holder |
TF×2 (Card 1 and Card 2 support circular storage) |
||
|
Power supply |
Power supply |
Original car battery, 12V/24V power supply |
|
|
Button& Indicator light
|
Reset button |
Multiplexing the Power button (hidden), long press the power button for 8 seconds to reset |
|
|
indicator light |
2-color indicator |
||
|
Alarm key |
Standard emergency alarm connector |
||
|
Antenna
|
GPS Antenna |
Built-in ceramic antenna |
|
|
4G antenna |
FPC+IPEX transposon |
||
|
WIFI antenna |
FPC+IPEX transposon |
||
|
Memory card |
4G～2TB, patented DXR streaming storage format |
||
|
Electrical Specification |
Operating temperature |
-20℃～70℃ |
|
|
Storage temperature |
-40℃～85℃ |
||
|
Static Protection |
6KV contact, 10KV air |
||
|
Vibration test |
car vibration |
||
|
Current consumption |
When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.) In flameout state: ≤3mA |
||
|
Other quality requirements |
According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.) |
||
Advanced driver assistance features（ADAS）
|
Alarm Type |
Illustrate DASH CAM |
Default enable condition |
Remark |
|
Forward Collision Warning (FCW) |
Real-time monitoring of the distance between the vehicles ahead can warn the driver as early as 2.7 seconds before a collision is expected to prevent rear-end collisions. Voice prompt: Collision hazard |
Speed ≥ 30km/h |
Optional |
|
Lane Departure Warning (LDW) |
Monitor the current lane markings and vehicle trajectory and issue an alarm when it is about to deviate from the lane unintentionally, reminding the driver to keep driving in a safe lane. Voice prompt: Lane departure |
Speed ≥ 30km/h |
Optional |
|
Distance Monitoring and Warning (HMW) |
Displays the distance (in seconds) of the vehicle ahead and warns when approaching a preset dangerous distance. Voice prompt: Be careful of the car ahead |
Speed ≥ 30km/h |
Optional |
Driver Status Monitoring Function (DSM)
|
Alarm Type |
Illustrate |
Default enable condition |
Remark |
|
Fatigue driving warning |
Recognition of closed eyes and yawning states (classified as mild and severe) |
Speed ≥ 30km/h |
Optional |
|
distraction alert |
Voice prompt: please pay attention to danger |
Speed ≥ 30km/h |
Optional |
|
call alert |
Recognize persistent head-to-side and low/head-up states |
Speed ≥ 30km/h |
Optional |
|
smoking warning |
Voice prompt: Please pay attention to road conditions |
Speed ≥ 30km/h |
Optional |
|
Driver Change Tips |
Recognize phone call gestures |
Speed ≥ 30km/h |
Optional |
|
Invalidation prompt |
Voice prompt: please do not call |
Speed ≥ 30km/h |
Optional |
|
Recognize smoking posture |
Speed ≥ 30km/h |
Optional |
|
Parameter classification |
parameter item |
Score indicator dashcam |
Remark |
|
Basic parameters |
Exterior |
Dash Camera integrated with terminal |
Max 4-channel video version. |
|
product type |
4G DVR Car Video Terminal |
||
|
network standard |
4G full Netcom |
||
|
Memory |
256MB(Flash)+1GB(DDR) |
||
|
front camera |
1080P, MIPI Camera, 16:9 required, H:112°V:55° |
||
|
in-car camera |
AHD 720P, with light sensor/infrared night vision, |
||
|
DSM camera |
AHD Camera, single pass, infrared night vision, 16:9 required, H=60° V=42° |
||
|
Hardware function
|
GPS |
Support: GPS+BDS |
|
|
Wi-Fi |
802.11b/g/n |
||
|
trumpet |
8 ohms 1.5 watts, 1 channel, with sound cavity |
||
|
MIC |
Built-in dual silicon microphone design |
||
|
Accelerometer |
3-axis accelerometer |
||
|
Interface |
micro 5Pin USB |
USB×1, data interface |
|
|
BMW connector |
8Pin power supply (5-way IO input, SOS*2) |
||
|
5557-4 |
RS232×1 |
||
|
SIM card holder |
Micro SIM |
||
|
TF card holder |
TF×2 (Card 1 and Card 2 support circular storage) |
||
|
Power supply |
Power supply |
Original car battery, 12V/24V power supply |
|
|
Button& Indicator light
|
Reset button |
Multiplexing the Power button (hidden), long press the power button for 8 seconds to reset |
|
|
indicator light |
2-color indicator |
|
|
|
Alarm key |
Standard emergency alarm connector |
||
|
Antenna
|
GPS Antenna |
Built-in ceramic antenna |
|
|
4G antenna |
FPC+IPEX transposon |
||
|
WIFI antenna |
FPC+IPEX transposon |
||
|
Memory card |
4G～2TB, patented DXR streaming storage format |
||
|
Electrical Specification |
Operating temperature |
-20℃～70℃ |
|
|
Storage temperature |
-40℃～85℃ |
||
|
Static Protection |
6KV contact, 10KV air |
||
|
Vibration test |
car vibration |
||
|
Current consumption |
When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.) In flameout state: ≤3mA |
||
|
Other quality requirements |
According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.) |
||
