| Model: | Highway Guardra |
|---|---|
| Brand: | Wadley |
| Origin: | Made In China |
| Category: | Industrial Supplies / Construction Machine |
| Label: | Highway Guardrail Fo , Guardrail Installati , Sheet Forming Machin |
| Price: |
US $35000
/ pc
|
| Min. Order: | 3 pc |
| Last Online:08 May, 2024 |
Product Overview
Highway Guardrail Machine The highway guardrail board is composed of two corrugated steel guardrail boards and two uprights fixed and clamped between them, and the two uprights are fixed and clamped between the two corrugated steel guardrail boards. When a vehicle collides with it, because the corrugated steel guardrail has good crash resistance and energy absorption, it is not easy to be crashed, and at the same time it can play a good role in protecting the vehicle and the passengers.
Working process of highway guardrail roll forming machine:
Decoiler---- feeding ----guide ---straightening--- hydraulic punching ---roll forming ---cutting off---Receiving ---packing
Specification
|
Product Name |
Crash Barrier Roll Forming Machine |
|
Production Capacity |
15 m/min |
|
Voltage |
380/220/440V |
|
Dimension(L*W*H) |
13000*1200*1500 |
|
Weight |
13000kg |
|
Rolling thinckness |
2-3mm |
|
Feeding width |
738mm |
|
Raw material |
45 # steel hard chrome plated |
|
Cutting blade material |
DC53 quenching heat treatment |
|
Forming part |
Divided into Seiko wheel rotation molding, forming effect is good, reduce the wheel and the friction between the raw materials,
|
|
Main frame |
400H Steel |
|
Suitable material |
Galvanizedsteel Steel |
|
Control system |
PLC(imported Brand) |
|
Cutting type |
Automatic Hydraulic Cutting |
|
Decoiler |
8T Decoiler |
Machine Parts Detail
Material feeding platform
Feeding width:738mm
Punching holes device
Rollers and shafts :
45 # steel hard chrome plated
The brand of meter counter:Omron
accurate measurement of quantity and length.
Main motor power:double7.5kw
PLC control system :
The operator automatically runs through the set program and monitors the control process, and can monitor the equipment operating status, operating parameters and fault indications in real time. The operation method can be manual or automatic, and there are emergency stop buttons throughout the line, making it easy to handle emergencies and ensuring the safety of equipment and operators.
Cutting system:
shear material: DC53 quenching heat treatment
Automatic Hydraulic Cutting
Application
Company Profile
Workshop overview
FAQ
Q1.How to send my enquiry?
You can contact us by email, phone call, message (Whats APP, We Chat, Skype).
Q2.How long can I get feedback after enquiry?
We will reply you within 3 hours in working day.
Q3.Delivery time
Machines order takes 30 days after deposit payment received. Please inquiry sales.
Q4.What is the package? Is it suitable for shipment?
Machine is by waterproof cloth to covered. And be packed by standard exported wooden case with steel foot. It is very much strong for oversea transportation.
Q5.Payment term
30% T/T as down payment, balance 70% by T/T before delivery. If others payment terms, we can discuss the details. Welcome to inquiry sales.
Q6.How long is the warranty for machines?
Machines warranty is 12 months after receive goods. in Warranty time,we can provide new free parts for changing.
Q7.Can you engineer come to our place to help with machine installation & commission?
Yes, our engineers are available to travel to your place. Round flight tickets & accommodation will be at your cost.
