| Model: | - |
|---|---|
| Brand: | tamprinter |
| Origin: | Made In China |
| Category: | Industrial Supplies / Plate Making & Printing Machine |
| Label: | LPG Cylinder PRINTER , Gas Cylinder PRINTER , LPG Gas KEG PRINTER |
| Price: |
US $6000
/ set
|
| Min. Order: | 1 set |
| Last Online:05 Oct, 2024 |
|
item |
value |
|
Plate Type |
Screen Printer |
|
Applicable Industries |
Manufacturing Plant |
|
Condition |
New |
|
Place of Origin |
Guangdong, China |
|
Brand Name |
TAMPRINTER |
|
Usage |
Cylinder Printer |
|
Automatic Grade |
Automatic |
|
Color & Page |
Two colors |
|
Voltage |
1.5kw |
|
Dimensions(L*W*H) |
Customized |
|
Weight |
500KG |
|
Certification |
ISO |
|
Max. Print Area |
700*600mm |
|
Warranty |
1 Year |
|
Key Selling Points |
Long Service Life |
|
Machinery Test Report |
Provided |
|
Video outgoing-inspection |
Provided |
|
Warranty of core components |
1 Year |
|
Core Components |
Motor, PLC, Engine |
|
Production efficiency |
>2pcs/min |
|
Ink consumption |
≤2g/pc |
|
Color Range |
2 color once |
|
Cylinder Size |
6kg, 12kg, 25kg, 48kg, or Customized |
|
Cylinder Diameter |
250~800mm or Customized |
|
Cylinder Thickness |
2.65-4mm |
Features:
1: Cam-linkage mechanisms driving mode combined with PLC control system for effectively guarantee working stability, reliability,and most efficiency.
2: Reliability: Main components from Rexroth, Schneider, SMC, Mitsubishi international brand. The machines hardware parts are made by CNC directly from CAD.
3: Machine Frame & structures made by high-intensity aluminum alloy and stainless steel.
4: With PLC control system. Fast setup & quick tooling change over for customer's easy operation and adjustment.
5: Adopted with No-product- no print system, auto counter, safety alarm device.
6: Optional: Made based on the customer's special requirements. devices, antistatic dust removing
device, extra set flame treatment, UV/IR system, auto scrambler system, offloading conveyor, offloading robot arm to have bottles stand up on the off conveyor belt and any other customizations due to order.
7:Electronic UV Curing System for mostly power rate saving, assuring the UV lamp's longest life span,
adjustable UV identity from 20%-100%
Advantages:
1: Much Higher Working Capacity
2: Lower noise and perfect working stability because of the mechanical driven
3: High precised and perfect registering double-color printing
4: Easy setting up for tooling change between oval, round and flat shape bottles and containers
5: equipped with electronic control UV curing system for adjust the UV density ranges from 0-100%
FAQ
Q: What size of LPG cylinder your machine can produce?
A: 6kg, 12kg,15kgs and 50kgs LPG cylinder for cooking and other size according customers' requirement.
Q: Can you design machines according LPG cylinder technical drawing?
A: Sure, please send your technical drawing to us.
Q: What are the benefits to choose your machines?
A: Our machines are strong and reliable for long term industrial manufacturing
We need to know following information to quote you correct machineries:
1.Technical Drawing of the cylinders you want to make?
2.What size of cylinder you want to produce?(6kg, 12kg)
3.What diameter and thickness of the cylinder you want to make?
4.Are you new in this area or you already have some machines in the workshop?
5.Capacity you require, i.e. how many pieces and sizes you want to make per day?
