| Model: | LC-TH-400/2 |
|---|---|
| Brand: | LC |
| Origin: | Made In China |
| Category: | Industrial Supplies / Plate Making & Printing Machine |
| Label: | hot foil stamping , gilding press , Stamping machine |
| Price: |
-
|
| Min. Order: | 1 pc |
| Last Online:09 Jan, 2025 |
Advantages:
(1) Computer control, man-machine interface is easy to operate;
(2) The hot head is driven by servo motor,
(3) Hot stamping pressure, temperature, speed can be adjusted; Built-in self-counting;
(4) Automatic foil feeding, foil receiving and adjustable,
Main parameters:
(1) The switchboard power is about 7KW
(2) Hot stamping speed reference 400~500pcs/hx2 station
(subject to actual production)
(3) Perm size 400x400mm
(4) The maximum hot stamping area diameter 350mm
(5) Stamping temperature 0~399℃
(6) Power supply 380V
(7) Air pressure 5-7Bar
(8) Equipment size (floor area reference) about 2300*2012*1950mm
(9) Equipment weight (handling reference) about 600KG
