Application:

Suitable for flat surface printing, widely applied in many industries including stationary, toys, gift industry, electrical appliances, cosmetic, containers, etc. Especially for the glasses, PVC film, paper and plastic bag.

Machine Features

1. Microcomputer control each function action, high degree of automation, easy and convenient operation, built-in four-digit automatic counter.

2. With flat, plane printing function, printing stroke and speed adjustable to meet different printing requirements.

3. The working table can be adjusted up and down, left and right, and the plane swing angle fine-tuning, convenient and quick adjustment.

4. Pneumatic printing scraper control and with pressure adjustment system.

5. Stable and reliable microcomputer system controller.

6. Bright and clear blue display, showing the working status of the machine at any time.

7. Excellent quality AUTONICS sensor and perfect fault alarm system.

8. Convenient foot switch, easy to operate and maintain.

9. Light but strong alloy die-casting parts and wear-resistant imported bearing bushings.

10. International famous brand SMC, FESTO and other pneumatic components, independent printing and ink return speed control.

Parameter:

1.Model:LC-3050-S
2.Max print area:300*500mm
3.Max frame size:500*800mm
4.Belt width:600mm
5.Touch-screen:WEVIEW
6.Belt length:2000mm
7.Machine size:2000*1100*1600mm
8.Machine weight:350kg
9.Package size:2100*1200*1800mm
10.Package weight:380kg
