| Model: | bowei002 |
|---|---|
| Brand: | bowei |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Battery, Storage Battery & Charger |
| Label: | energy·storage , power bank , battery |
| Price: |
¥30000
/ pc
|
| Min. Order: | 1 pc |
| Payment Terms: | TT |
| Last Online:10 Sep, 2025 |
| Item | AC | Remark |
| Voltage Range | 380/400(-15%~15%)VAC | 50/60(-2.5~2.5)Hz |
| Rated Output Current | 145A | Subject To The Actual Product |
| Rated Power |
100kW(1.1 times long term, 1.2times 1min) |
- |
|
Total Current Harmonic Distortion Rate |
≤3%(Full Load) | - |
| Power Factor | -0.99 ~ +0.99 | - |
| Electrical Connection Mode | Three-Phase Four-Wire | - |
| Item | DC | Remark |
| Cell Type | LFP280Ah@0.5P | |
| PACK Group Scheme | 1P52S | |
| System Group Scheme | 1P260S | |
| Nominal Capacity | 232.96kWh | |
| Rated voltage | 832V | |
| Voltage Range | 728~936V | |
| DOD | 98% |
| Rated Charge And Discharge Power | 110kW | |
| Cycle Life | ≥5200 | 25ºC,0.5P/0.5P,80%SOH |
| Maximum System Efficiency | ≥87% | (No Auxiliary System Loss) |
|
Maximum Conversion Efficiency Of PCS |
98.5% | |
| Size(W*D*H) | 1450*1400*2350mm | |
| Weight | ≈2700kg | |
| Protection Level | IP54 |
