| Model: | - |
|---|---|
| Brand: | LC |
| Origin: | Made In China |
| Category: | Industrial Supplies / Plate Making & Printing Machine |
| Label: | Paint Line , Spray Coating System , Painting Machine |
| Price: |
US $75000
/ pc
|
| Min. Order: | 1 pc |
| Last Online:15 Oct, 2025 |
The fully automatic spray painting machine, with its high-speed operation of 7000 mm/min, large-scale capacity of 180 meters, precise spraying control at 0.5-0.7 MPa, adjustable smart baking at 180°C, and robust SUS stainless steel structure, collectively forms a top-tier coating production system. It not only significantly enhances product appearance quality and production efficiency but also reduces operational costs and optimizes production space for users through its exceptional stability and automation.
1.Speed :7000mm/min adjustable
2.Total Chain Length: 180meter (fixture 1771pcs)
3.Chain Pitch:50.8mm
4.Sprocket Diameter： 180mm
5.Indexing Pitch: 101.6mm
6.Drying tempreture: 180° adjustable
7.Air Pressure:0.5-0.7Mpa；
8.Total Power: 135KW
9.Voltage: Main Unit/220V 50Hz, Oven/3-phase 5-wire 380V 50Hz
10.The main frame structure is fabricated by welding SUS square tubing, with housing panels formed from bent SUS sheet metal.
11.Process Flow:Manual Loading → Brushing Washing/electrostatic dust removal → Automatic Spray Coating → Leveling → Baking → Cooling → Manual Unloading → Continuous Cycle
