| Model: | WES-300B |
|---|---|
| Brand: | EAST |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Laboratory Instrument |
| Label: | TESTING MACHINE , TESTER , universal testing |
| Price: |
-
|
| Min. Order: | 1 pc |
| Last Online:09 Oct, 2022 |
|
model
|
YE-2000A
|
||
|
(KN)maximum test force
|
2000
|
||
|
testing space
|
(mm) upper and lower plate dimensions
|
Φ280
|
|
|
(mm) maximum distance of upper and lower plate
|
300
|
||
|
(mm) distance between upright
|
330×170
|
||
|
(kN) & (kN/grid)
measuring rang & minimum division value
|
0-200
|
0.5
|
|
|
0-400
|
1.00
|
||
|
0-500
|
1.00
|
||
|
0-800
|
1.00
|
||
|
0-1000
|
2.00
|
||
|
0-2000
|
4.00
|
||
|
maximum magnitude for relative error of indicating value
|
±1.0%
|
||
|
maximum permissible value of relative variable of displaying value
|
1%
|
||
|
maximum permissible value of process and reverse relative error of displaying value
|
1.5%
|
||
|
Load keeps for 30 seconds, the variable of displaying value does not exceeds the largest testing force
|
0.5%
|
||
|
(mm)working Piston Travel
|
80
|
||
|
(mm) external dimension(L×W×H)
|
main body
|
1140×820×1560
|
|
|
dynamometer
|
750×630×600
|
||
|
(kW) motor power
|
1.5
|
||
|
(kg) net weight
|
1200
|
||
