| Model: | M100 |
|---|---|
| Brand: | SCTI |
| Origin: | Made In China |
| Category: | Security & Protection / Surveillance Equipment |
| Label: | thermal imaging came , thermal imaging , thermal imaging core |
| Price: |
-
|
| Min. Order: | 1 pc |
| Last Online:28 Aug, 2020 |
|
Items |
M100 |
|
|
Detector characteristic |
Detector |
Micro Focal plane array |
|
Array format/pixel pitch |
384x288/25um |
|
|
Sensitivity |
≤80mk@ 300K,50HZ |
|
|
Frame rate |
50Hz |
|
|
Spectral response |
8～14um |
|
|
Image |
A/D Resolution |
14bit |
|
Video D/A |
10bit |
|
|
No shutting technology |
Yes |
|
|
Thermal image adjustment |
Image Polarity |
Black hot/White hot |
|
Noise reduction |
Yes |
|
|
Electronic Zoom |
2x |
|
|
Power |
Voltage |
2.2～5.5V |
|
Power consumption |
0.65W |
|
|
Environment |
Operating temperature range |
-20℃～60℃ |
|
Humidity |
95% Non-condensing |
|
|
Physical characteristic |
Weight(No lens) |
48g |
|
Dimensions(No lens) |
50x45x21mm |
|
|
Interface |
External DC input |
Yes |
|
Video output |
PAL |
|
|
Keyboard |
4 buttons keyboard |
|
| Payment Terms: | TT |
|---|---|
