1.     Specification

1)     Product capability: 20-35pcs/min

2)     Diametr of the center tube:30-75mmLength of center tube to be processed: any length required

3)     Steel plate thickness:0.25-0.32mm

4)     Motor power: 3kw

5)     Power supply:380V 50Hz

6)     Working air pressure:0.6Mpa

7)     Machine weight:800kg

8)     Size of the main machine: 1600x800x1240mm (LxWxH)

9)     Size of the paper decoiler:1200x800x760mm(LxWxH)

2.     Features

1)     The machine can easily change the diameter of screw tube in a short time.

2)     Cut the needed length according to customer’s require.

3)     Can adjust the clutch according to the different thickness of the steel strip.

4)     The computer control machine can save production costs and working procedures with it high efficiency,steady quality and economical materials.

5)     Adopts hydraulic pressure drive,which has stron power and good stable.

3.     Applications

The machine is technically used in manufacturing the tube of filters
