XJ2壁挂/墙面式iPAD自助终端

XJ2壁挂/墙面式iPAD自助终端
型号：XJ2
品牌：ZKTEK
原产地：中国
类别：电脑、影音数码 / 网络硬件和部件
标签︰不锈钢ipad终端 , 不锈钢ipad机壳 , 不锈钢ipad支架
单价： ¥360 / 件
最少订量：1 件
发送查询

产品描述

Model Number:XJ2

Features



  • Wallmounted IPAD kiosk enclosure
  • 9.7″ main touchscreen
  • WIFI/3G/BlueTooth wireless
  • Protected HOME Key
  • Protected HD camera
  • Ventilation enhanced enclosure for new ipad.
  • with credit card reader and blue tooth printer options.
  • All steel anti-graffiti enclosure stand

Introduction

XJ2 is a wallmounted all-metal steel ipad kiosk with lockable front panel.

XJ2 datasheet


Applications





Internet browsing,Exhibition,Apps store,Presentation,Information kiosk,advertisement,loyalty card verification,hotel login,service

Technical details



Operation System
  • WINDOWS XP
  • WINDOWS 7
  • Linux 2.6 distribution(i.e. Fedora 9, CentOS 5, Ubantu 10 and SUSE etc)
Processor
  • Dual-core Apple A5X custom-designed,
  • with quad-core graphics
Display
  • Retina display
  • 9.7-inch (diagonal) LED-backlit glossy widescreen display with IPS technology
  • 2048-by-1536-pixel resolution at 264 pixels per inch (ppi)
Touchscreen
  • Multi-Touch Capacitive
Cameras, Photos, and Video
  • 5-megapixel iSight camera
  • Autofocus
  • Tap to focus
  • Face detection in still images
  • Video recording, HD (1080p) up to 30 frames per second with audio
  • Video stabilization
  • FaceTime camera with VGA-quality photos and video at up to 30 fps
  • Photo and video geotagging
Credit Cardreader(optional)
  • Magnetic card(optional): ISO7810, ISO7811 Track 1/2/3
Printer(optional)
  • Printer type: direct thermal
  • Printing resolution: 384dot per line
  • Paper type: thermal paper
  • Paper thickness: 0.06-0.08
  • Paper width: 58mm(printing area width: 48mm)
  • Speed: 100mm/s
  • Max paper roll diameter: 140mm
  • Max printing life: 50km
  • Interface: Bluetooth 4.0 technology
Rear I/O Connectors
  • 30-pin dock connector port
  • 3.5-mm stereo headphone minijack
  • Built-in speaker
  • Microphone
  • Micro-SIM card tray
Enclosure
  • All steel anti-graffiti enclosure
  • Available in cold roll steel
  • Optional Brushed, anodized aluminum or powder coating surface
Power consumption
  • Built-in 42.5-watt-hour rechargeable lithium-polymer battery
  • Up to 10 hours of surfing the web on Wi-Fi, watching video, or listening to music
  • Up to 9 hours of surfing the web using cellular data network
  • Power and Charging via power adapter or USB to computer system
Operating System
  • iOS
Reliability
  • Operation Temperature: 0~35°C
  • StorageTemperature: -20~45°C
  • Operating RH: 0-95%(NC)
  • Max operation latitue: 10000 m
  • Power supply: 110V AC 5A/220V AC 3A
  • IP protection: Front IP54(with only contactless card and touchscreen)
  • IK protection: IK05
  • electrostatic protection: 1500V
  • impedance: 10kOhm
  • EMC Standard: It is compliance with the council EMC directive 89/336/EEC,EN55022: 1988+A1:2000+A2:2003,EN55024: 1988+A1:2001+A2:2003.
  • Emission: EN 50081-1.
  • Immunity: EN 50082-1.
Physical Characteristic
  • Material: 1.5mm all steel
  • Dimensions:tbd
  • Gross weight:20KG
  • Net weight: 15KG
付款方式︰全款预付
