电气配线软管系列 ELECTCAL WIRING HOSE SERIES
FPA 阻燃尼龙软管
Flame retardant nylon hose
颜色:黑色、灰色
温度范围:-40℃~+120℃,短时可达+150℃
防护等级:IP65
阻燃等级:V0
材质:尼龙6
特性:1.柔韧性佳,机械强度高
2.耐磨,耐压,抗扭曲,不断裂,不变形
3.耐油、酸、碱,抗紫外线,绝缘,不含卤素、磷、镉
Color:Black、Grey
Temperature Range:-40℃~+120℃,short-time +150℃
Protection Degree:IP65
Flame Retardant Grade:V0
Materal:Polyamide 6
Property:1.Excellent flexibility, high mechanical strength
2.Abrasion resistance, compression, distortion, fracture, deformation
3.Oil resistance, acid, alkali, UV resistance, insulation, no halogen, phosphorus, cadmium
型号 规格 内径 外径 弯曲半径 包装规格
FPAB100 FPAG100 AD10.0 6.5 10.0 15 100
FPAB130 FPAG130 AD13.0 10.0 13.0 25 100
FPAB158 FPAG158 AD15.8 12.0 15.8 35 100
FPAB185 FPAG185 AD18.5 14.3 18.5 40 100
FPAB212 FPAG212 AD21.2 17.0 21.2 45 50
FPAB285 FPAG285 AD28.5 23.0 28.5 55 50
FPAB345 FPAG345 AD34.5 29.0 34.5 65 25
FPAB425 FPAG425 AD42.5 36.0 42.5 90 25
FPAB545 FPAG545 AD54.5 48.0 54.5 100 25
FPAB800 FPAG800 AD80.0 66.5 80.0 170 10
FPAB106 FPAG106 AD106.0 91.0 106.0 225 10
青岛弘科电气有限公司
李先生
13687658273
