Insulation material绝缘材料......................................................PPE

Rated current额定电流..............................................................3.5.8.10.12.15A

Rated voltage额定电压..............................................................1000V(TUV)＆600V(UL)

Test voltage测试电压................................................................6kv(50Hz,lmin

Typical contact resistance接触电阻.......................................... ≤ 5mΩ

Contact material接解材质.........................................................Copper,Tin plated

Degree of protection防护等级..................................................IP2X/IP67

Safety degree适合防护等级.......................................................II

Flame class防火等级..................................................................UL94-V0

Material RTI使用材料最高温度....................................................110℃

Withdrawal force拔出力............................................................ ≥ 50N

Insertion force插入力................................................................ ≤ 50N

Ambient temperature range使用温度.........................................-40℃ until+85℃

Pin dimensions端子直径..............................................................Ф4.0

Suitable cable cross section适合的电缆截面...............................2.5/4.0/6.0mm²
