型号: | 各种 |
---|---|
品牌: | 斯特尔 |
原产地: | 中国 |
类别: | 工业设备 / 矿业设备 |
标签︰ | 实验强磁选机 , 磁选管 , 弱磁选机 |
单价: |
¥24200
/ 台
|
最少订量: | 1 台 |
试验室鼓形湿法弱磁选机技术参数
Technical Parameter of laboratory Drum Wet Low-intensity Magnetic Separator
XCRS湿式弱磁选机用于金属选矿实验室,矿业工程实验,中间实验厂,它利用湿式方法对细粒磁性矿石进行磁选,选别形式为顺流。磁选机体积小,重量轻,操作简单。该设备不宜进行带有腐蚀性液体的选矿试验。本产品由原地矿部唯一指定企业生产,执行行业标准。
该机转鼓内装开式磁系,当给矿时能迅速的分选出磁性矿物,磁性矿物在槽体中被磁力吸在鼓面上,受磁力搅拌下甩掉污泥,最后随鼓面旋转借助于冲水排出机外。
XCRS Wet Magnetic Separator is mainly desgned for labs for netallic mineral processing.Tt conducts concurrent magnetic separation of fine-grain ores with strong magnetism by wse of Wet Method.It is small in volume,light in weight,simple in operation and convenient in maintenance.However,it is unsuitable to be used in beneficiation by the former corrosive. The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Mineral Resources,in compliance with the Industrial standards
Drum machine built with open magnetic system, as to the mine quickly when the sub-elected magnetic minerals, magnetic minerals in the tank was in the dark magnetic suction surface, get rid of sludge by magnetic stirring and finally with the drum heads With flush discharged outside the rotating machine.
型号Model |
单位 Uite |
XCRS 400/300 |
磁鼓尺寸Magneric impeller size |
mm |
400/300 |
磁鼓转速Rotating speed |
r/min |
25 |
处理量Caparating size |
kg/h |
20-60 |
给料粒度Feed size |
mm |
3 |
磁场强度 Intensity |
GS |
1250(100KA/m)无级可调 |
电压 Voltage |
V |
380 |
功率power |
kw |
0.25 |
配套辅机Supply equipment |
taiwan |
激磁电源1台 |
外形Overall dimensions |
mm |
783/600/1200 |
重量Weighe |
kg |
250 |
