自助终端设备 IC卡 310电动读卡器

产品描述

Quick Details

Place of Origin:	Guangdong, China (Mainland)	Brand Name:	YSDA	Model Number:	CRT-310
Name:	Kiosk motor card reader(RS232/USB/TTL) CRT-310	Card standard:	IC Card:ISO7816 Magnetic card:ISO7810ID-1,7811 RFID Card:iso:14443-A	Read or Write:	IC/RFID card reader/write,Mag card read only
Interface:	RS-232/TTL	Magnetic Head:	500,000 cycles min	IC card Contact:	300,000 cycles min
Motor:	500,000 cycles min	Power supply:	DC12V+-5%	Certification:	EMV
Weight:	410g

Packaging & Delivery

Packaging Details:	paper carton
Delivery Detail:	7 days

Specifications

1.Kiosk motor card reader(RS232/USB/TTL) CRT-310
2.IC/RF card read/write
3.With function of motor front/rear insert

Applications:

Kiosk terminals

Payment systems

Access control terminals

Specifications:

Card standard	Magnetic Card: ISO7810 ID-1,ISO7811 IC Card: ISO7816-2 RF Card: ISO14443 TYPE A&B
Life time	Magnetic head:500,000 passes IC card contact:300,000 passes Motor:300,000 passes
Current consumption	Static Current: 110mA Peak Current: <1.5A
Temperature/Humidity	Operation:0~50℃/0 ~ 90% RH(Non condensing) Storage:-20~70℃/0 ~ 90% RH(Non condensing)
Dimension (LxWxH)	148x86x48mm
Weight	Approx 410g
