概括：适合工业机器视觉.图像检测系统,医学影像检测系统的应用范围

1/3寸逐行扫描,38万像素,黑白小型,高速工业相机

1/3寸IT逐行扫描CCD
 高帧速 – 全帧模式60帧每秒BINNED模式下120帧每秒
 高速扫描以提高帧率，部分扫描情况下可达到200帧每秒
 由VD 脉宽控制的部分扫描
 方形象素
 最低照度达到 1 lux @ F1.8
 水平分辨率 - 500TV 线
 小巧，紧凑机身- 29 (W) x 29 (H) x 30 (D)/50g
 外触发功能
 结实耐用 -10G抗抖动/70G抗震
 C-Mount / 无 IR 滤光片

指标                                              详细
成像器件                                        1/3 寸逐行扫描CCD
成像器件色值                                  单色黑白
像素尺寸                                        7.4μm x 7.4μm
有效分辨率                                     648x494 - VGA
有效象素                                        659x494
相机界面                                        模拟
镜头安装方式                                  C-Mount
Flange Back                                 17.526 mm
垂直频率                                        31.468 kHz ±1 %
外同步信号                                     HD/VD
JITTER（颤抖值）                           低于20ns
同步系统                                        内同步/外同步
扫描系统                                        逐行扫描
增益                                              固定/手动
Gamma                                        OFF关闭 fixed固定
标准快门；                                     标准快门
                                               Restart重新启动/Reset重新设置
                                               外触发快门        (Mode 1/MODE 2)
外触发快门 / 速度                           1/4 to 1/100000s
外触发                                           极性: +宽: 2 μs to 250ms
                                                    输入阻抗: 10 kΩ 或更多 (H: +2 to +5.0V
                                                    L: 0 to 0.6V)
                                                    极性: +宽: 2 μs to 250ms
高速扫描                                        R/R模式 Binning模式关闭:
                                                    最高 240 帧/秒
                                                    R/R 模式 Binning 模式开启:
                                                    最高360 帧/秒
                                                    外触发快门模式 Binning模式关闭 :
                                                    最高 240帧/秒
                                                    外触发快门模式 Binning模式开启
                                                    最高 360帧/秒
输出信号频率；                               59.94Hz (标准模式)
                                             119.98 Hz (binning模式)
快门速度                                        OFF关闭 到 1/30000s 后面板处可调
视频输出指标                                  详细信息
水平分辨率                                     500TV线
最低照度                                        1.0 lux (F1.4 Manual gain Max)
输出连接口                                     12PIN
信噪比                                           58dB
灵敏度                                           400 lux F5.6 (Fix Gain 0 dB)
视频输出                                        1.0 Vp-p Sync negative75 ?
                                                    Unbalanced
综合指标                                        详细情况
尺寸(W x H x D)                            (29 x 29 x 30 mm)
重量                                              50 g (2 oz)
电源要求                                        DC 12 V (+10.5 to 15 V)
功率消耗                                        1.8 W
工作温度                                        -5 to 40°C (23 to 113 °F)
存放温度                                        -30 to 60 °C (-22 to 140 °F)
工作湿度                                        20 to 80 % (no condensation)
存放湿度                                        20 to 95 % (no condensation)
抖动抵抗限度                                  10G (20 Hz to 200 Hz)
震动抵抗限度                                  70 G
符合标准                                        UL 6500 FCC Class A Digital Device
                                                    CE (EN61326/97+A1/98)
                                                    AS4251.1+A4252.1

尺寸(W x H x D)：                               (29 x 29 x 30 mm)
电源适配器：DC-700CE
连接线缆：CMCC-12P2/12P05/12P10
也可配本公司生产的简易电源
工业相机连接线CCXC-12P02N/05N/10N
还有各式工业相机镜头
