不锈钢工业流体输送用焊管A312 GB/T 12771
| 型号： | - |
|---|---|
| 品牌： | OEM |
| 原产地： | 中国 |
| 类别： | 建筑、装饰 / 建筑用管和附件 / 钢管 |
| 标签︰ | 不锈钢焊管 , 工业焊管 , GB/T 12771不锈钢焊管 |
| 单价： |
-
|
| 最少订量： | - |
产品描述
不锈钢工业流体输送用焊管A312 GB/T 12771
材质：304/L, 316/L
尺寸：1“~20”
| Standrads | Specification | Materials/Grade | Dimension(OD&WT) | 说明 |
| ASTM A270 / A270M | Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing | TP304,TP304L,TP316,TP316L | 19-304.8mm; 1.2-3mm | 卫生设施用无缝和焊接奥氏体和铁素体/奥氏体不锈钢钢管 |
| ASTM A312 / A312M | Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes | TP304,TP304L,TP316,TP316L | 6.35-2133.6mm; 0.5-30mm | 无缝和焊接奥氏体不锈钢公称管 |
| ASTM A554 | Welded Stainless Steel Mechanical Tubing | MT304,MT304L,MT316,MT316L | 12.7-114.3mm; 0.7-6.5mm | 机械构造用不锈钢焊接钢管 |
| ASTM A249 / A249M | Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser Tubes | TP304,TP304L,TP316,TP316L | 15.9-139.8mm; 1.6-5.0mm | 锅炉、过热器、换热器和冷凝器用焊接奥氏体钢管子 |
| ASTM A269 / A269M | Seamless and Welded Austenitic Stainless Steel Tubing for General Service | TP304,TP304L,TP316,TP316L | 15.9-139.8mm; 1.6-5.0mm | 一般用途奥氏体不锈钢无缝及焊接钢管 |
| ASTM A409 / A409M | Welded Large Diameter Austenitic Steel Pipe for Corrosive or High-Temperature Service | TP304,TP304L,TP316,TP316L | 6.35-2133.6mm; 0.5-30mm | 腐蚀场所或高温下使用的焊接大口径奥氏体钢管 |
| ASTM A778 / A778M | Welded, Unannealed Austenitic Stainless Steel Tubular Products | TP304,TP304L,TP316,TP316L | 6.35-2133.6mm; 0.5-30mm | 焊接未退火的奥氏体不锈钢管形制品 |
| ASTM A358 / A358M | Electric-Fusion-Welded Austenitic Chromium-Nickel Stainless Steel Pipe for High-Temperature Service and General Applications | TP304,TP304L,TP316,TP316L | 6.35-2133.6mm; 0.5-30mm | 高温用电熔焊奥氏体铬镍合金钢管 |
| ASTM A790 / A790M | Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe | TP304,TP304L,TP316,TP316L | 6.35-2133.6mm; 0.5-30mm | 无缝及焊接的铁素体-奥氏体不锈钢公称管 |
| ASTM A789 / A789M | Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service | TP304,TP304L,TP316,TP316L | 6.35-2133.6mm; 0.5-30mm | 一般用途无缝焊接铁素体和奥氏体不锈钢管 |
| GB/T 12771 | Welded stainless steel pipes for liquid delivery | S30408,S30403,S31608,S31603 | 6.35-2133.6mm; 0.5-30mm | 流体输送用不锈钢焊管 |
| JIS G3446 | Stainless steel pipes for machine and structural purposes | SUS304,SUS304L,SUS316,SUS316L,SUS321,SUS317,SUS317L,SUS310S,SUS347 | 12.7-114.3mm; 0.7-6.5mm | 机械结构用不锈钢钢管 |
| JIS G3463 | Stainless steel boiler and heat exchanger tubes | SUS304,SUS304L,SUS316,SUS316L,SUS321,SUS317,SUS317L,SUS310S,SUS347 | 15.9-139.8mm; 1.6-5.0mm | 锅炉与热交换器用不锈钢钢管 |
| JIS G3448 | Light gauge stainless steel pipes for ordinary piping | SUS304,SUS304L,SUS316,SUS316L,SUS321,SUS317,SUS317L,SUS310S,SUS347 | 12.7-318.5mm; 0.8-3.0 | 普通管路用不锈钢钢管 |
| EN 10217-7 | Welded steel tubes for pressure purposes. Technical delivery conditions Part7:stainless steel tubes | 1.4301,1.4306,1.4845,1.4401,1.4571,1.4404, | 承压用焊接钢管交货技术条件 第7部分 不锈钢管 | |
| DIN11850 | Stainless steel pipes for the food industry dimensions materials | 1.4301,1.4306,1.4845,1.4401,1.4571,1.4404, | 食品和化学工业用不锈钢管.尺寸丶材料 |
