Diameter range

Φ80-Φ1500mm

Tube Length

120-8000mm

Thickness of Strip

0.4-1.2mm

Width of Strip

137-140mm

Strip Speed

1-38/min

Dimension (L x W x H):

2650*1550*2000mm

Lockseam

Outside tube,on the inside on request

Weight

2200kg

Control System

PLC automatic control

Compressed air power

0.5-0.7kmp

Electrical

380V/3PH/50HZ

(Acorrding to customer’s request)

Main Motor Power

5.5kw

The power of cutting motor

4kw

Suitable Material

Aluminum, Stainless steel, Galvanized steel
