Plug-In/Sloted-box PLC Splitter:

The optical fiber can distribute the optical fiber signal to all ports evenly.

The loss is insensitive to wavelength and can meet the transmission needs of different wavelengths.

High quality imported chips with low polarization dependent loss can meet different wavelength requirements.

Easy installation and convenient operation.

HOMOGENEITY OF LIGHT

The uniformity of light distribution is good, and the optical fiber

signal can be evenly distributed to the users.

TRANSMISSION STABILITY

The loss is insensitive to wavelength and can meet the transmission

needs of different wavelengths

HIGH QUALITY CERAMIC INSERT

High quality imported ceramic insert is selected for its excellent

performance, stability and durability.

HIGH QUALITY IMPORTED OPTICAL CHIPS

Imported transmission chips are used to ensure uniform and stable light splitting,

low polarization-related loss and low ejection reflection,

which can meet the needs of different wavelengths.

TELECOM ENGINEERING GRADE COUPLER

High quality imported ceramic bushing is used to isolate other

interference signals effectively.

The number of pl ing is high and the loss is low.

EASY INSTALLATION SPACE

It can be directly installed in the distributor and press the nuts on both sides,so that the operation is convenient.



PLC Stainless tube splitter:

PLC optical splitter is an integrated waveguide optical power distribution device based on quartz substrate. It has the characteristics of small size, wide operating wavelength range, high reliability and good uniformity. It is especially suitable for passive optical networks (EPON, BPON, GPON, etc.) connects the central office and the terminal device and implements the splitting of the optical signal.

1. The micro PLC optical splitter encapsulates the PLC splitter chip and the input and output fiber arrays in a square metal tube, and leads the optical path through a bare fiber with a diameter of 0.9mm or 250um. The optical fiber can be welded or processed. A variety of fiber optic connectors.

2. We can provide 1×N and 2×N full range of products, and customize optical splitters for various applications. All products are in compliance with the "YD/T1117-2001 all-fiber branch device technical conditions", "YD/T 2000.1-2014 planar optical waveguide integrated optical circuit device based on planar optical waveguide (PLC) optical power splitter" and other standards, and Certified by Tell (TLC) products.



Rack PLC splitter:

The 19-inch standard structure design, the size of the knot, a wide range of adaptation.

The adapter interface can be provided according to the customer's requirements. It is equipped with SC as standard, which is more cost-effective than the wall-mounted solution.

The spectroscopic technical indicators meet the YD/T893 industry standard requirements.

1. Loss is not sensitive to the wavelength of light and can meet the transmission needs of different wavelengths.

2. The dust cap effectively protects the jack from foreign matter and reduces the light performance.

3. Evenly distributed light, the signal can be distributed to customers evenly

4. Compact structure, can be directly installed in the existing various exchange boxes without leaving a large installation space.



PLC box splitter:

ABS Box Splitter (PLC Splitter) is an integrated waveguide optical power distribution device based on quartz substrate. It has the characteristics of small size, wide operating wavelength range, high reliability and good uniformity of splitting. It is especially suitable for passive. In the optical network (EPON, BPON, GPON, etc.), the central office and the terminal device are connected and the optical signal is split. There are currently two types of 1×N and 2×N. The 1 x N and 2 x N splitters evenly divide the optical signal into multiple outlets from a single or dual inlet, or work in reverse to direct multiple optical signals into a single or dual fiber.

1. Evenly splitting, the fiber signal can be evenly distributed to the users.

2. High-quality imported splitting chip Adopt imported transmission chip to ensure uniform and stable splitting, low polarization-dependent loss and low ejection reflection, which can meet different wavelength requirements.

3. Environmentally friendly PVC quilt The anti-pull pit has strong performance, low-carbon and halogen-free environmental protection, safe to use, and practical.

4. High-quality ceramic ferrules Good uniformity of splitting, can distribute the fiber signal evenly to the users.

5. Meet the transmission needs of different wavelengths The loss is not sensitive to the wavelength of the transmitted light, and can be slow to transmit for different wavelengths.

Available for customized order based on customer's drawing or clear requirements; Please contact technical support for details:
