| Catalog |
Function Description |
| Optiacal performance |
Magnification power 3.5 X31 (MAX 7x) |
| Digital Zoom 2 steps magnification, Max 2x |
| Angle Of View 9° |
| Objective Aperture 31mm |
| Exit Pupil Distance 30mm |
| F# for Objective lens 1.2 |
| 3m~∞ in daytime; Viewing in the darkness up to 400M (monochrome) |
| Eyepiece magnification 2x |
| Video Output |
320x240 resolution TFT LCD |
| OSD menu display |
| CVBS always output with VGA resolution |
| Imager |
Wide Dynamic Range High-sensitivity CMOS Sensor |
| Size 1/3'' |
| Resolution 640X480 |
| IR LED |
3W Infared LED with 850nm |
| Micro SD Card |
Support SDHC 4GB~32GB SD Card |
| Hardware Buttons |
Power on/off |
| Snap |
| Mode selection |
| Zoom |
| IR switch |
| Operation |
Preview |
| Record JPEG file in SD storage |
| Capture JPEG file in SD storage |
| Playback media file from SD storage |
| Power |
External power supply - DC 5V/1A |
| 8 pcs AA battery 4.5V-6V |
| Battery life: 6 hours working time with IR off |
| Battery low warning |
| System |
4 modes (Capture, Video, Playback) |
| Single frame Image Capture |
| Video image Record |
| Playback image |
| Delete image |
| 5 level IR switch |
| SD card format |
| Power save (Off/1 min/ 3min/50 min) |
| Language: English /Trad. Chinese /Simp. Chinese /Japanese / |
| French /Deutsch /Korean /Italian /Portuguese /Russian / Spanish / Arabic |
| System Rest |
| Light Freq. 50/60HZ |
| Date Input |
| Version |
