玻璃光纤束组件

玻璃光纤束组件
型号:Customized
品牌:3V-TECH
原产地:中国
类别:电子、电力 / 仪器、仪表 / 光学透镜和仪器
标签︰玻璃光纤束 , 光纤束连接器 , 光纤束组件
单价: ¥380 / 米
最少订量:10 米
发送查询
点击这里给我发消息

产品描述

3V TECHNOLOGY provides various types of bundled glass fiber products to realize light conduction and light shaping, light homogenizing, light collecting, light beam splitting, etc., make your optical system more efficient,more personalized with our customization support. It can also be assembled with collimating lens and coupling lens to collimate, converge and,beam expansion, etc., to optimize the performance of the optical system.

Typical application:

Industrial field;Medical field,Scientific research

▷ Smoke detection

▷ Particle detection

▷Endoscope

▷ Testing instrument

▷laser therapy

▷Fluorescence excitation

▷Quanlity controlling

▷DNA analysis

▷ Spectrum analysis

▷Colorimetric analysis

▷Protein analysis

▷Sensor  ▷Remote lighting  ▷Flame analysis

▷Cold light source

▷Laser transmission

Performance Parameter:

▷Transmission wavelength range(nm):380-1200
▷NA value:0.56 ± 0.02
▷Single fiber’s diameter:30um/50um
▷Projective outside tube:PVC,Stainless steel braided hose or customize
▷Fiber Bundle’s diameter(mm):3/5/8/10 or customize
▷Fiber Bundle’s length(m):1.0/1.5/2.0/3.0/5.0 or customize
▷Temperature resistance range:-40~120℃、-40~250℃;
▷Assembled customized lens is supportable(like collimating lend,focusing lens)

付款方式︰TT
玻璃光纤束组件 1玻璃光纤束组件 2玻璃光纤束组件 3玻璃光纤束组件 4玻璃光纤束组件 5
