The  Rotating Hoist Ring UNC range has been expanded with three extra sizes from WLL 6.8t up to 13.6t.

The  Rotating Hoist Ring UNC is a grade 8 rotating hoist ring with UNC thread. This hoist ring with UNC thread can

pivot 180掳 and rotate 360掳. It has UNC threads as standard. The cylindric head of the screw prevents jamming during rotation of the shackle.

The WLL indicated hereunder are given in the worst conditions of use, i.e. 90掳. It is necessary to check the free moving of the pivoting shackle. WLL and CE marking are mentioned on the product. The minimum safety factor is 5:1.

Rotating Hoist Ring UNC is available in a range with a working load limit from 0.4t up to 13.6t.

Additional information on the hoist rings are available on the tel

ADA Rotating Hoist Ring UNC, Grade 8 rotating ring

ADA Rotating Hoist Ring UNC GR8

Product code: ADAUNC

Material: alloy steel, Grade 8, quenched and tempered

Safety Factor: MBL equals 5 x WLL

Finish: painted white

Temperature range: -40掳C up to +200掳C (-40掳F up to +392掳F)

Certification:CE

Note: WLL indicated hereunder are given in the worst

conditions of use, i.e. 90掳

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 5/16", WLL 0.4 t

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 3/8", WLL 0.6 t

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 1/2", WLL 1 t

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 5/8", WLL 1.7t

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 3/4", WLL 2.5 t

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 7/8", WLL 3.5 t

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 1", WLL 4.5 t

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 1 1/4", WLL 6.8 t

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 1 1/2", WLL 10.8 t

ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 2", WLL 13.6 t
